Pepperl Fuchs VBG-EP1-KE5-D
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Ethernet Devices |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can VBG-EP1-KE5-D be shipped?
VBG-EP1-KE5-D is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up VBG-EP1-KE5-D in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for VBG-EP1-KE5-D and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for VBG-EP1-KE5-D, subject to availability and destination.
AS-Interface gateway. PROFINET / EtherNet/IP gateway for 1 AS-Interface network. AS-Interface specification: V3.0. Earth fault detection: integrated. Diagnostics function: Extended function via diagnostics interface. UL File Number: E223772. MTBF: at 40 °C 60.7 a. LED indication: see manual. Button: Saving the Configuration and Reset. Rated operating voltage: from AS-Interface 18 ... 31.6 V from AUX 20 ... 30 V. Rated operating current: ≤ 220 mA from AS-Interface segment 1 ≤ 170 mA from AUX. Protection class: III. Nominal voltage: from AS-Interface 30 V DC from AUX 24 V DC. Interface type: Fieldbus. Physical: 2 x RJ-45. Protocol: PROFINET IO with media redundancy protocol (MRP) and S2 system redundancy. EtherNet/IP with Device Level Ring (DLR) HTTP (REST API). Transfer rate: 10 MBit/s / 100 MBit/s , Automatic baud rate detection. IP address: via DHCP. Interface type: Service interface. Physical: 1 x RJ45. Transfer rate: 100 MBit/s. IP address: 192.168.1.2. Interface type: SD card slot. Ethernet: RJ45. AUX/AS-Interface: removable spring clamp terminals. Electromagnetic compatibility: . Directive 2014/30/EUEN 62026-2:2013 EN 61000-6-2:2005, EN 61000-6-4:2007: . Directive 2014/30/EU: EN 62026-2:2013 EN 61000-6-2:2005, EN 61000-6-4:2007. Electromagnetic compatibility: EN 61000-6-2:2005, EN 61000-6-4:2007. Degree of protection: EN 60529:2000. AS-Interface: EN 62026-2:2013. Shock resistance: EN 61131-2:2004. Ambient temperature: -25 ... 60 °C (-13 ... 140 °F). Storage temperature: -40 ... 85 °C (-40 ... 185 °F). Cold start temperature: -40 °C (-40 °F). Relative humidity: ≤ 95 % non-condensing. Altitude: ≤ 5000 m above MSL [Ambient temperature max. 40 °C). Degree of protection: IP20 (Manufacturer declaration). Material: PA 66-FR. Mass: 185 g. Dimensions: . Height125 mmWidth38 mmLength99 mm: . Height: 125 mm. Width: 38 mm. Length: 99 mm. Construction type: DIN-rail mounting
Specifications
General specifications
| AS-Interface specification | V3.0 |
| Earth fault detection | integrated EFD |
| Diagnostics function | Extended function via diagnostics interface |
| UL File Number | E223772 |
| MTBF | at 40 °C 60.7 a |
Indicators/operating means
| LED indication | see manual |
| Button | Saving the Configuration and Reset |
Electrical specifications
| Rated operating voltage | from AS-Interface 18 ... 31.6 V from AUX 20 ... 30 V Ue |
| Rated operating current | ≤ 220 mA from AS-Interface segment 1 ≤ 170 mA from AUX Ie |
| Protection class | III |
| Nominal voltage | from AS-Interface 30 V DC from AUX 24 V DC UN |
Interface 1
| Interface type | Fieldbus |
| Physical | 2 x RJ-45 |
| Protocol | PROFINET IO with media redundancy protocol (MRP) and S2 system redundancy. EtherNet/IP with Device Level Ring (DLR) HTTP (REST API) |
| Transfer rate | 10 MBit/s / 100 MBit/s , Automatic baud rate detection |
| IP address | via DHCP |
Interface 2
| Interface type | Service interface |
| Physical | 1 x RJ45 |
| Transfer rate | 100 MBit/s |
| IP address | 192.168.1.2 |
Interface 3
| Interface type | SD card slot |
Connection
| Ethernet | RJ45 |
| AUX/AS-Interface | removable spring clamp terminals |
Directive conformity
| Electromagnetic compatibility | |
| Directive 2014/30/EUEN 62026-2:2013 EN 61000-6-2:2005, EN 61000-6-4:2007 | Directive 2014/30/EU |
| Directive 2014/30/EU | EN 62026-2:2013 EN 61000-6-2:2005, EN 61000-6-4:2007 |
Standard conformity
| Electromagnetic compatibility | EN 61000-6-2:2005, EN 61000-6-4:2007 |
| Degree of protection | EN 60529:2000 |
| AS-Interface | EN 62026-2:2013 |
| Shock resistance | EN 61131-2:2004 |
Ambient conditions
| Ambient temperature | -25 ... 60 °C (-13 ... 140 °F) |
| Storage temperature | -40 ... 85 °C (-40 ... 185 °F) |
| Cold start temperature | -40 °C (-40 °F) |
| Relative humidity | ≤ 95 % non-condensing |
| Altitude | ≤ 5000 m above MSL [Ambient temperature max. 40 °C) |
Mechanical specifications
| Degree of protection | IP20 (Manufacturer declaration) |
| Material | PA 66-FR |
| Mass | 185 g |
| Dimensions | |
| Height125 mmWidth38 mmLength99 mm | Height |
| Height | 125 mm |
| Width | 38 mm |
| Length | 99 mm |
| Construction type | DIN-rail mounting |
