Pepperl Fuchs VBA-LT2-G1
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Safety at Work |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can VBA-LT2-G1 be shipped?
VBA-LT2-G1 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up VBA-LT2-G1 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for VBA-LT2-G1 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for VBA-LT2-G1, subject to availability and destination.
AS-Interface luminous push-button module. Illuminated pushbutton module. Node type: A/B node. AS-Interface specification: V2.11. Required gateway specification: ≥ V2.1. Profile: S-B.A.E. IO codeBID codeAID2 codeE: . IO code: B. ID code: A. ID2 code: E. LED PWR/FAULT: dual-LED green/redgreen: AS-Interface voltage, normal operationred: communication error or address 0. Button: 2 integrated,protected against accidental activation,keys can be individually labelled,labeling field on the module. Rated operating voltage: 26.5 ... 31.6 V from AS-Interface. Rated operating current: ≤ 50 mA (LEDs on). Protection class: III. Electromagnetic compatibility: EN 50295. Degree of protection: EN 60529:2000. AS-Interface: EN 62026-2:2013. Ambient temperature: -25 ... 60 °C (-13 ... 140 °F). Storage temperature: -40 ... 85 °C (-40 ... 185 °F). Degree of protection: IP67 according to EN 60529. Connection: cable piercing method or terminal compartmentflat cable or standard round cable
Specifications
General specifications
| Node type | A/B node |
| AS-Interface specification | V2.11 |
| Required gateway specification | ≥ V2.1 |
| Profile | S-B.A.E |
| IO codeBID codeAID2 codeE | IO code |
| IO code | B |
| ID code | A |
| ID2 code | E |
Indicators/operating means
| LED PWR/FAULT | dual-LED green/redgreen: AS-Interface voltage, normal operationred: communication error or address 0 |
| Button | 2 integrated,protected against accidental activation,keys can be individually labelled,labeling field on the module |
Electrical specifications
| Rated operating voltage | 26.5 ... 31.6 V from AS-Interface Ue |
| Rated operating current | ≤ 50 mA (LEDs on) Ie |
| Protection class | III |
Standard conformity
| Electromagnetic compatibility | EN 50295 |
| Degree of protection | EN 60529:2000 |
| AS-Interface | EN 62026-2:2013 |
Ambient conditions
| Ambient temperature | -25 ... 60 °C (-13 ... 140 °F) |
| Storage temperature | -40 ... 85 °C (-40 ... 185 °F) |
Mechanical specifications
| Degree of protection | IP67 according to EN 60529 |
| Connection | cable piercing method or terminal compartmentflat cable or standard round cable |
