Pepperl Fuchs KT-LED-24-TC-24VDC
LED temperature display
- MPN
- KT-LED-24-TC-24VDC
- Category
- Process Displays
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Pepperl Fuchs KT-LED-24-TC-24VDC?
Temperature display in °C or °F
Resolution up to 0.1 °C
Extremely bright, large LED indicator
For thermocouples J, K, and N
Galvanic isolation
Polarity reversal protected
Degree of protection IP65 (front only)
Temperature display in °C or °F, Resolution up to 0.1 °C, Extremely bright, large LED indicator, For thermocouples J, K, and N, Galvanic isolation, Operating voltage: 10 ... 30 V DC galvanically isolated, Dimensions: 48 mm x 24 mm x 68.3 mm
Specifications
General specifications
| Order code (Pepperl+Fuchs part number) | 215126 |
| Data storage | EEPROM |
| Programming | keypad-driven menu |
| Lifecycle | Active (current Pepperl+Fuchs product) |
Indicators/operating means
| Type | 5-digit 7-segment LED display, red |
| Display value | digit height 8 mm |
| Display interval | -999.9 ... 1999.9 |
| Decimal point | 0 to max 1 fractional digit |
| Temperature range | acc. DIN IEC 584:J (Fe-Cu-Ni): -210 ... 1200 °C (-346 ... 2192 °F) K (Ni-CrNi): -200 ... 1372 °C (-328 ... 2501.6 °F) N (NiCrSi-NiSi): -200 ... 1300 °C (-328 ... 2372 °F) |
| Resolution | 0.1 °C (0.1 °F) bzw. 1 °C (1 °F) |
| Refresh cycle of the measured value output | 1 - 2 s-1 |
| Reset | manually or external |
Electrical specifications
| Operating voltage | 10 ... 30 V DC galvanically isolated UB |
| Operating current | max. 40 mA IB |
Input
| Suitable sensors | Thermocouple J, K, N, with sensor breakage monitoring |
| Signal voltage | Display latch, display hold for current measured value |
| High | 4 ... 30 V DC |
| Low | 0 ... 2 V DC |
| Counting frequency | 5 measurements per second |
| Linearity error | < 0.4 % at 20°C ambient temperature |
| Compensation (reference junction CJC) | internal or external (programmable) Junction error: ±1.0 °C typ./±3.0 °C max. |
Compliance with standards and directives
| Directive conformity: EMC Directive 2004/108/EC | EN 61000-6-2:2005 |
| Standard conformity: Emitted interference | DIN EN 55011:2009, Class B |
Ambient conditions
| Ambient temperature | -20 ... 65 °C (-4 ... 149 °F) |
| Storage temperature | -25 ... 70 °C (-13 ... 158 °F) |
| Relative humidity | ≤ 85 % (non-condensing) |
| Temperature drift | 0.1 K/Kenvironment |
Mechanical specifications
| Degree of protection | IP65 (front) |
| Mass | approx. 45 g |
| Dimensions | 48 mm x 24 mm x 68.3 mm |
