Mechanical accessories for linear axes Parts
Compare Mechanical accessories for linear axes
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Weight [kg] | Dimension A (profiled rail systems) [mm] | Dimension B (profiled rail systems) [mm] | Dimension C [mm] | Dimension D [mm] |
|---|---|---|---|---|---|
| R344700601 | 0.03 | 19 | 8.8 | 12 | 10 |
| R039175003 | 0.02 | 13 | 6 | 10 | 8 |
| R039175004 | 0.03 | 15 | 6 | 12 | 10 |
| R344200301 | 0.01 | 13 | 4 | — | — |
| R913001655 | 0.01 | 8 | 4 | — | — |
| R344200200 | 0.02 | 16 | 8 | — | — |
| R344701002 | 0.02 | — | — | — | — |
| R341201002 | 0.01 | — | — | — | — |
| R341201102 | 0.01 | — | — | — | — |
| R039171061 | 0.06 | 10 | 19.5 | 10.5 | 5 |
| R039171007 | 0.1 | 10 | 19.5 | 10.5 | 5 |
| R039171008 | 0.03 | 8 | 16 | 6 | 2 |
| R039171009 | 0.02 | 6 | 11.5 | 4 | 1 |
| R117530117 | 1.58 | 104 | 68 | — | — |
| R117510117 | 0.72 | 70 | 56.5 | — | — |
| R117560117 | 4 | 145 | 99 | — | — |
| R344700301 | 0.02 | 15 | 6 | 12 | 10 |
| R344700201 | 0.02 | 15 | 6 | 12 | 10 |
| R344700101 | 0.01 | 13 | 6 | 10 | 8 |
| R039660549 | 0.01 | — | — | 5.5 | 3.5 |
| R039660548 | 0.01 | — | — | 3.4 | 3.5 |
| R039660544 | 0.01 | — | — | 6.6 | 4 |
| R039660547 | 0.01 | — | — | 3.4 | 3 |
