Mechanical accessories for linear axes Parts
Compare Mechanical accessories for linear axes
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Weight [kg] | Outer diameter D [mm] | Dimension A (profiled rail systems) [mm] | Dimension B (profiled rail systems) [mm] | Dimension D [mm] |
|---|---|---|---|---|---|
| R039171006 | 0.04 | — | — | — | — |
| R039171004 | 0.39 | — | — | — | — |
| R039171001 | 0.2 | — | — | — | — |
| R039171000 | 0.2 | — | — | — | — |
| R039171003 | 0.06 | — | — | — | — |
| R039171005 | 0.06 | — | — | — | — |
| R344702001 | 0.01 | 2.0 | 8 | 16 | 2 |
| R344701901 | 0.01 | 2.0 | 8 | 16 | 2 |
| R344701801 | 0.01 | 2.0 | 8 | 16 | 2 |
| R344701701 | 0.01 | 2.0 | 8 | 16 | 2 |
| R344701501 | 0.01 | 1.0 | 6 | 11.5 | 1 |
| R344701401 | 0.01 | 1.0 | 6 | 11.5 | 1 |
| R039171038 | 0.01 | 1.7 | 5 | 9.2 | 1.7 |
| R344700901 | 0.02 | 5.0 | 10 | 19.5 | 5 |
| R344701001 | 0.02 | 5.0 | 10 | 19.5 | 5 |
| R344701101 | 0.03 | 5.0 | 10 | 19.5 | 5 |
| R344701201 | 0.03 | 5.0 | 10 | 19.5 | 5 |
| R037521021 | 0.01 | 0.4 | 4 | 7.8 | 0.4 |
| R037521020 | 0.01 | 0.4 | 4 | 7.8 | 0.4 |
| R117509008 | 0.01 | — | — | — | — |
