XI2 Digital Outputs Parts
Compare XI2 Digital Outputs
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Number of channels | Bit width, output data in the process data image | Maximum power dissipation in the module [W] | Current requirement Up | Net current module outputs [A] |
|---|---|---|---|---|---|
| R911421647 | 2 | 12 Bytes | 1.81 | 1.05 A | 1 |
| R911421645 | 4 | 12 Bytes | 1.805 | — | 2 |
| R911421644 | 2 | 12 Bytes | 1.805 | 1.05 mA | 1 |
| R911420202 | 2 | 1 byte | 1.2 | 25 mA | 4 |
| R911406103 | 2 | 1 byte | 1.2 | 25 mA | 2 |
| R912009223 | 16 | 2 Bytes | — | — | 4 |
| R911417209 | 4 | 1 byte | — | 15 mA + load | 8 |
| R911406101 | 8 | 1 byte (8 bits) | 2.25 | 15 mA + load | 4 |
| R911417208 | 4 | 1 byte | 1 | 15 mA + load | 2 |
| R911406102 | 16 | 2 bytes (16 bits) | 2.25 | 30 mA + load | 4 |
Common to all listed parts
| Connection type | Push-in |
| Width [mm] | 12 |
| Height [mm] | 105 |
| Depth [mm] | 99 |
| International protection code | IP20 |
| Protection class | III |
| Backplane-Bus | Standard-EtherCAT über LVDS |
| EMC resistance | EN 61000-6-2 and EN 61000-6-4 |
