Siemens 5SE2310
NEOZED fuse-link, D01, 10 A, gG, Un AC: 400 V, Un DC: 250 V, with tin-coated contact-caps
- MPN
- 5SE2310
- Category
- NEOZED Fuse Links
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Siemens 5SE2310?
NEOZED fuse-link, D01, 10 A, gG, Un AC: 400 V, Un DC: 250 V, with tin-coated contact-caps
Specifications
Model
| product brand name | SENTRON |
| product designation | NEOZED fuse link |
| design of the product | With tin-coated contact caps |
| product version | Pack of 10 |
| design of the fuse link | NEOZED fuse link |
General technical data
| size of fuse system according to EN 60269-1 | D01 |
| operating class of the fuse link | gG |
Supply voltage
| supply voltage — at AC | 400 V |
| supply voltage — at DC | 250 V |
| operating voltage rated value | 400 V |
| protection class IP | IP20, with connected conductors |
| switching capacity current according to IEC 60947-2 rated value | 50 kA |
Dissipation
| power loss [W] for rated value of the current at AC in hot operating state per pole | 1 W |
Main circuit
| operational current rated value | 10 A |
Appearance
| color coding of the fuse link | Red |
| maximum short-circuit current breaking capacity (Icu) at AC rated value | 50 kA |
Mechanical Design
| mounting position | Any, preferably vertical |
| Net Weight | 7 g |
| ambient temperature during operation — minimum | -25 °C |
| ambient temperature during operation — maximum | 40 °C |
| environmental category | Up to 45°C at 95 % rel. humidity |
No matching specifications
Downloads & documentation
Official documents from Siemens, downloaded directly from the manufacturer.
Data sheets & manuals
5SE2310: frequently asked questions
When can 5SE2310 be shipped?
5SE2310 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 5SE2310 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 5SE2310 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 5SE2310, subject to availability and destination.
