Schneider Electric NSYMUC158
Screwed-on cut-out cover plate, PanelSeT SFN, SF, SM, for electrical enclosure W800mm, 1 cut out, H150mm
- MPN
- NSYMUC158
- EAN
- 3606480066467
- Category
- PanelSeT SM
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the Schneider Electric NSYMUC158?
This is a screwed-on cut-out cover plate for modular switchgear (1 module = 18 mm) suitable for PanelSeT SFN, PanelSeT SF and PanelSeT SM electrical enclosures. It is compatible with enclosures that have a width of 800mm. Suitable by modules of 150 or 200 mm. The nominal height and width are 150mm and 800mm respectively. The real height, width and depth are 702mm, 149.5mm and 12mm respectively. It is made of steel. The color is grey RAL7035. Anti-corrosion protection is ensured by an epoxy-polyester zinc coated coating. The kit contains 1 cut-out cover plate and fixing elements.
Specifications
Specifications
| Range | PanelSeT |
| Accessory / separate part category | Enclosure accessory |
| Product or component type | Cover plate |
| Anwendung | Multi-purpose |
| Range compatibility | PanelSeT SF, PanelSeT SM |
| Nominal dimensions of the housing | - H: 150 mm W: 800 mm |
| Mounting location | On chassis coupling set |
| Device composition | Fixing elements, 1 cover plate |
| Quantity per set | Set of 1 |
| Material | Steel |
| Colour | Grey (RAL 7035) |
| Surface finish | Epoxy-polyester powder |
| Fixing mode | By screws |
| Number of horizontal rows | 1 |
| Total number of 18 mm modules | 36 |
| Type of front plate | With cut-out |
| Number of cut-out | 1 cut-out |
| Height | Nominal: 150 mm, Real: 149.5 mm |
| Width | Nominal: 800 mm, Fixing centers: 678 mm, Real: 702 mm |
| Depth | Real : 12 mm |
Packaging
| Package 1 | 1 PCE, 1.500 cm × 15.000 cm × 70.500 cm (L × W × H), 1.436 kg |
| Package 2 | 125 PAM, 120.000 cm × 100.000 cm × 46.000 cm (L × W × H), 193.000 kg |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
NSYMUC158: frequently asked questions
When can NSYMUC158 be shipped?
NSYMUC158 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up NSYMUC158 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for NSYMUC158 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for NSYMUC158, subject to availability and destination.
