Ethernet fibre converter SM/LC 2CH - 100 MB

Name: Ethernet fibre converter SM/LC 2CH - 100 MB
Brand: Schneider Electric
SKU: 140NRP31201

MPN: 140NRP31201 · Brand: Schneider Electric

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Modicon Quantum
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	0.55 kg

Shipping & availability

When can 140NRP31201 be shipped?

140NRP31201 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 140NRP31201 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 140NRP31201 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 140NRP31201, subject to availability and destination.

Specifications

Range of product	Modicon Quantum automation platform
Product or component type	Fibre converter
Optic fiber type	Single mode
Bus current requirement	1000 mA
Power dissipation in W	5 W
Inrush current	1 A at 5 V DC
Number of port	2 fiber optic, connector type: LC, 2 ETHERNET, connector type: RJ45
Local signalling	1 LED green with RDY marking for module status, 1 LED red with ERR marking for internal fault, module failure, 1 LED green with STS1 marking for channel 1 link status, 1 LED green with FX1 ACT marking for channel 1 communication status, 1 LED green with STS2 marking for channel 2 link status, 1 LED green with FX2 ACT marking for channel 2 communication status
Wavelength	1310 nm
Optic distance between 2 transceivers	15000 m (9/125 µm), optical power: -15…-8 dBm
Attenuation	-15…-8 dB (9/125 µm)
Rise/fall time	2.5 ns
Receiver sensitivity	- 28 dBm
Detected silence	-45 dBm
Marking	CE
Material	PC (polycarbonate)
Width	40.34 mm
Height	250 mm
Depth	103.85 mm
Net weight	0.554 kg
Ambient air temperature for operation	0…60 °C
Ambient air temperature for storage	-40…85 °C
Relative humidity	0…95 %
Operating altitude	0...2000 m
Standards	UL 508, CSA C22.2 No 142, FM Class 1 Division 2
Product certifications	TÜV, Merchant Navy, C-Tick
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	16.3 cm
Package 1 Width	4.5 cm
Package 1 Length	31.2 cm
Package 1 Weight	614.0 g
Unit Type of Package 2	S03
Number of Units in Package 2	7
Package 2 Height	30.0 cm
Package 2 Width	30.0 cm
Package 2 Length	40.0 cm
Package 2 Weight	4.298 kg
