Home / Schneider Electric / Modicon Quantum / Modicon Quantum DIO head-end adaptor - fibre optic cable medium

Available on request

Schneider Electric 140NOM25200C – Modicon Quantum DIO head-end adaptor - fibre optic cable medium

MPN: 140NOM25200C · Brand: Schneider Electric

Price on request

Discontinued by Schneider Electric — we can still source the original 140NOM25200C (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Modicon Quantum
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)
UPC / EAN	3595861136984
Datasheet	Manufacturer datasheet ↗

Shipping & availability

Can I still buy the 140NOM25200C now that it is discontinued?

Yes. Schneider Electric has discontinued the 140NOM25200C, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can 140NOM25200C be shipped?

140NOM25200C is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 140NOM25200C in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 140NOM25200C and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 140NOM25200C, subject to availability and destination.

Schneider Electric 140NOM25200C — Modicon Quantum DIO head-end adaptor - fibre optic cable medium. Discontinued by Schneider Electric. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of product	Modicon Quantum automation platform
Product or component type	DIO head-end adaptor

Complementary

Number of port	1 Modbus Plus fiber optic single copper; 1 Modbus RS232 twisted pair
Transmission rate	1 Mbit/s
Electrical connection	1 connector RJ45; 2 connectors TX/RX
I/O words	30 I/32 O
Checks	RAM; Checksum; Processor; RAM address
Power dissipation in W	4 W
Minimum pulse width distortion/jitter	5 ns
Wavelength	820 nm
Power loss budget	11 dB 62.5/125 µm; 16.5 dB 100/140 µm; 6.5 dB 50/125 µm
Optical transmission	-16…-9 dBm 100/140 µm; -19.8…-12.8 dBm 50/125 µm; -3.5…110.5 dBm 62.5/125 µm
Rise/fall time	20 ns
Dynamic range	20 dB
Detected silence	-36 dBm
Sensitivity scale	> 30 dBm
Bus current requirement	750 mA

Environment

Resistance to electrostatic discharge	4 kV contact conforming to IEC 801-2; 8 kV on air conforming to IEC 801-2
Resistance to electromagnetic fields	10 V/m 80…2000 MHz conforming to IEC 801-3
Ambient air temperature for operation	0…60 °C
Ambient air temperature for storage	-40…85 °C
Relative humidity	95 % without condensation
Operating altitude	<= 5000 m
Protective treatment	Conformal coating Humiseal 1A33
Standards	UL 508
Product certifications	RINA; RMRS; DNV; GOST; GL; CSA Class 1 Division 2; C-Tick
