Axial piston variable pumps Parts
























Compare Axial piston variable pumps
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Weight [kg] | Control device | Rotational speed [rpm] | Max. displacement [cm³] | Max. flow [l/min] |
|---|---|---|---|---|---|
| R902557889 | 12 | DR remote controlled | 3300.0 | 18.0 | 59.4 |
| R902557888 | 8 | DR remote controlled | 2400.0 | 10.5 | 25.2 |
| R902557887 | 8 | DR remote controlled | 3600.0 | 8.1 | 29.1 |
| R902557886 | 8 | DR remote controlled | 2400.0 | 10.5 | 25.2 |
| R902557885 | 9.1 | DR remote controlled | 2400.0 | 10.5 | 25.2 |
| R902534337 | 89.4 | DR F controller X-T open 32/53 | 1800.0 | 180.0 | 324.0 |
| R902566715 | 80 | Power controller <160bar, DRS | 1500.0 | 140.0 | 210.0 |
| R902566711 | 76 | DR F controller X-T plugged 32/53 | 1500.0 | 140.0 | 210.0 |
| R902542497 | 68 | Power controller, DRS | 1500.0 | 140.0 | 210.0 |
| R902514124 | 90.2 | DR F controller X-T plugged 32/53 | 1800.0 | 140.0 | 252.0 |
| R902493031 | 65.4 | Power controller, DRS | 1500.0 | 140.0 | 210.0 |
| R910998787 | 67.13 | Power controller, DRS | 1450.0 | 140.0 | 203.0 |
| R902460930 | 67 | Power controller, DRS | 1450.0 | 140.0 | 203.0 |
| R910946057 | 65.4 | Pressure controller | 1500.0 | 140.0 | 210.0 |
| R910945253 | 65.4 | DR F controller X-T plugged 31/52 | 1500.0 | 140.0 | 210.0 |
Common to all listed parts
| Version_1 | Standard |
| Version_2 | Standard |
| Direction of rotation | clockwise (w.view on shaft end) |
| Sealing material | FKM (standard) |
| Connector for solenoids | Without |
| Min. displacement [cm³] | 0.0 |
| Min. flow [l/min] | 0.0 |
| Internal drain line | No |
