Beckhoff
ZK7102-BF00-AxxxB12, ENP cable, PUR, 2 x 0.75 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Hybrid cables Parts
Beckhoff
ZK7102-BG00-0xxxB12, ECP cable, PUR, 2 x 0.75 mm² + (1 x 4 x AWG22), drag-chain suitable,key 1 (24 V DC)
Beckhoff
ZK7102-BG00-AxxxB12, ENP cable, PUR, 2 x 0.75 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7102-BH00-0xxxB12, ECP cable, PUR, 2 x 0.75 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7102-BH00-AxxxB12, ENP cable, PUR, 2 x 0.75 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7102-BI00-0xxxB12, ECP cable, PUR, 2 x 0.75 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7102-BI00-AxxxB12, ENP cable, PUR, 2 x 0.75 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7102-BJ00-0xxxB12, ECP cable, PUR, 2 x 0.75 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7102-BJ00-AxxxB12, ENP cable, PUR, 2 x 0.75 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-1800-0xxxB17, ECP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-1800-AxxxB17, ENP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-1819-0xxxB17, ECP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-1819-AxxxB17, ENP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-1900-0xxxB17, ECP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-1900-AxxxB17, ENP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-AG00-0xxxB17, ECP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-AG00-AxxxB17, ENP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-AH00-0xxxB17, ECP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-AH00-AxxxB17, ENP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-AI00-0xxxB17, ECP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-AI00-AxxxB17, ENP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-AJ00-0xxxB17, ECP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-AJ00-AxxxB17, ENP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-AK00-0xxxB17, ECP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Compare Hybrid cables
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Contact type | A2 | A3 | A4 | A5 |
|---|---|---|---|---|---|
| ZK7102-BF00-Axxx | male | 20.00 mm | 17.40 mm | 31.00 mm | — |
| ZK7102-BG00-0xxx | male | 24.40 mm | 16.50 mm | 31.00 mm | M18 |
| ZK7102-BG00-Axxx | male | 24.40 mm | 16.50 mm | 31.00 mm | M18 |
| ZK7102-BH00-0xxx | male | 24.40 mm | 16.50 mm | 31.00 mm | M18 |
| ZK7102-BH00-Axxx | male | 24.40 mm | 16.50 mm | 31.00 mm | M18 |
| ZK7102-BI00-0xxx | male | WAF24 | 16.50 mm | 19.50 mm | 12.50 mm |
| ZK7102-BI00-Axxx | male | WAF24 | 16.50 mm | 19.50 mm | 12.50 mm |
| ZK7102-BJ00-0xxx | male | WAF24 | 16.50 mm | 19.50 mm | 12.50 mm |
| ZK7102-BJ00-Axxx | male | WAF24 | 16.50 mm | 19.50 mm | 12.50 mm |
| ZK7206-1800-0xxx | male+male | 23.00 mm | — | — | — |
| ZK7206-1800-Axxx | male+female | 23.00 mm | — | — | — |
| ZK7206-1819-0xxx | female+ female | 23.00 mm | — | — | — |
| ZK7206-1819-Axxx | female+male | 23.00 mm | — | — | — |
| ZK7206-1900-0xxx | female+ female | 23.00 mm | — | — | — |
| ZK7206-1900-Axxx | female+male | 23.00 mm | — | — | — |
| ZK7206-AG00-0xxx | male | 25.00 mm | 20.00 mm | 20.30 mm | 14.00 mm |
| ZK7206-AG00-Axxx | male | 25.00 mm | 20.00 mm | 23.00 mm | 14.00 mm |
| ZK7206-AH00-0xxx | male | 25.00 mm | 20.00 mm | 19.00 mm | 14.00 mm |
| ZK7206-AH00-Axxx | male | 25.00 mm | 20.00 mm | 19.00 mm | 14.00 mm |
| ZK7206-AI00-0xxx | male | 30.40 mm | 21.00 mm | 29.00 mm | 8.00 mm |
| ZK7206-AI00-Axxx | male | 30.40 mm | 21.00 mm | 29.00 mm | 8.00 mm |
| ZK7206-AJ00-0xxx | male | 30.40 mm | 21.00 mm | 25.00 mm | 8.00 mm |
| ZK7206-AJ00-Axxx | male | 30.40 mm | 21.00 mm | 25.00 mm | 8.00 mm |
| ZK7206-AK00-0xxx | male | WAF30 | 22.00 mm | 18.00 mm | 19.00 mm |
Common to all listed parts
| Connector type | plug |
| Wire termination | crimp connection |
| Cross-section (Ethernet) | 1 x 4 x 0.34 mm² (AWG22) |
| Use | drag-chain suitable |
| Material jacket | PUR (polyurethane) |
| Max. number of cycles | 3 million |
| CE | yes |
