Beckhoff
ZK7206-AK00-AxxxB17, ENP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Hybrid cables Parts
Beckhoff
ZK7206-AL00-0xxxB17, ECP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-AL00-AxxxB17, ENP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-BK00-0xxxB17, ECP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-BK00-AxxxB17, ENP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-BL00-0xxxB17, ECP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-BL00-AxxxB17, ENP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-BM00-0xxxB17, ECP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-BM00-AxxxB17, ENP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-BN00-0xxxB17, ECP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-BN00-AxxxB17, ENP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-BO00-0xxxB17, ECP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-BO00-AxxxB17, ENP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-BP00-0xxxB17, ECP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7206-BP00-AxxxB17, ENP cable, PUR, 3 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (24 V DC)
Beckhoff
ZK7208-3000-0xxxB17, ECP cable, PUR, 5 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (2 x 24 V DC + PE)
Beckhoff
ZK7208-3000-AxxxB17, ENP cable, PUR, 5 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (2 x 24 V DC + PE)
Beckhoff
ZK7208-3031-0xxxB17, ECP cable, PUR, 5 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (2 x 24 V DC + PE)
Beckhoff
ZK7208-3031-AxxxB17, ENP cable, PUR, 5 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (2 x 24 V DC + PE)
Beckhoff
ZK7208-3100-0xxxB17, ECP cable, PUR, 5 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (2 x 24 V DC + PE)
Beckhoff
ZK7208-3100-AxxxB17, ENP cable, PUR, 5 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (2 x 24 V DC + PE)
Beckhoff
ZK7208-AS00-0xxxB17, ECP cable, PUR, 5 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (2 x 24 V DC + PE)
Beckhoff
ZK7208-AS00-AxxxB17, ENP cable, PUR, 5 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, (2 x 24 V DC + PE)
Beckhoff
ZK7208-AT00-0xxxB17, ECP cable, PUR, 5 G 1.5 mm² + (1 x 4 x AWG22), drag-chain suitable, key 1 (2 x 24 V DC + PE)
Compare Hybrid cables
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Contact type | Number of positions (face) | Outer cable diameter | A2 | A4 |
|---|---|---|---|---|---|
| ZK7206-AK00-Axxx | male | 3-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | WAF30 | 18.00 mm |
| ZK7206-AL00-0xxx | male | 3-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | WAF30 | 14.00 mm |
| ZK7206-AL00-Axxx | male | 3-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | WAF30 | 14.00 mm |
| ZK7206-BK00-0xxx | male | 3-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | 25.00 mm | 37.00 mm |
| ZK7206-BK00-Axxx | male | 3-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | 25.00 mm | 33.00 mm |
| ZK7206-BL00-0xxx | male | 3-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | 25.00 mm | 33.00 mm |
| ZK7206-BL00-Axxx | male | 3-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | 25.00 mm | 33.00 mm |
| ZK7206-BM00-0xxx | male | 3-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | 30.40 mm | 37.00 mm |
| ZK7206-BM00-Axxx | male | 3-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | 30.40 mm | 37.00 mm |
| ZK7206-BN00-0xxx | male | 3-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | 30.40 mm | 33.00 mm |
| ZK7206-BN00-Axxx | male | 3-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | 30.40 mm | 33.00 mm |
| ZK7206-BO00-0xxx | male | 3-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | SW30 | 27.00 mm |
| ZK7206-BO00-Axxx | male | 3-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | WAF30 | 27.00 mm |
| ZK7206-BP00-0xxx | male | 3-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | SW30 | 23.00 mm |
| ZK7206-BP00-Axxx | male | 3-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | WAF30 | 23.00 mm |
| ZK7208-3000-0xxx | male+male | pins 4+PE+4 | 11.0 mm ± 0.2 mm (0.4331" ± 0.0079") | 23.00 mm | — |
| ZK7208-3000-Axxx | male+female | pins 4+PE+4 | 11.0 mm ± 0.2 mm (0.4331" ± 0.0079") | 23.00 mm | — |
| ZK7208-3031-0xxx | female+ female | pins 4+PE+4 | 11.0 mm ± 0.2 mm (0.4331" ± 0.0079") | 23.00 mm | — |
| ZK7208-3031-Axxx | female+male | pins 4+PE+4 | 11.0 mm ± 0.2 mm (0.4331" ± 0.0079") | 23.00 mm | — |
| ZK7208-3100-0xxx | female+ female | pins 4+PE+4 | 11.0 mm ± 0.2 mm (0.4331" ± 0.0079") | 23.00 mm | — |
| ZK7208-3100-Axxx | female+male | pins 4+PE+4 | 11.0 mm ± 0.2 mm (0.4331" ± 0.0079") | 23.00 mm | — |
| ZK7208-AS00-0xxx | male | 5-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | 25.00 mm | 23.00 mm |
| ZK7208-AS00-Axxx | male | 4-wire | 6.5 mm ± 0.2 mm (0.142" ± 0.0079") | 25.00 mm | 23.00 mm |
| ZK7208-AT00-0xxx | male | 5-wire | 6.5 mm ± 0.2 mm (0.2559" ± 0.0079") | 25.00 mm | 19.00 mm |
Common to all listed parts
| Connector type | plug |
| Wire termination | crimp connection |
| Cross-section (Ethernet) | 1 x 4 x 0.34 mm² (AWG22) |
| Use | drag-chain suitable |
| Material jacket | PUR (polyurethane) |
| Max. number of cycles | 3 million |
| CE | yes |
