EtherCAT and fieldbus cables Parts

Beckhoff

ZK1090-3332-0xxx

EtherCAT cable, PUR, AWG26, drag-chain suitable

Beckhoff

ZK1090-3333-0xxx

EtherCAT cable, PUR, AWG26, drag-chain suitable

Beckhoff

ZK1090-3363-0xxx

EtherCAT cable, PUR, AWG26, drag-chain suitable

Beckhoff

ZK1090-3391-0xxx

EtherCAT cable, PUR, AWG26, drag-chain suitable

Beckhoff

ZK1090-3891-0xxx

EtherCAT cable, PUR, AWG26, drag-chain suitable

Beckhoff

ZK1090-6100-0xxx

EtherCAT cable, PUR, AWG22, drag-chain suitable

Beckhoff

ZK1090-6100-4xxx

EtherCAT cable, PUR, AWG26, drag-chain suitable

Beckhoff

ZK1090-6161-0xxx

EtherCAT cable, PUR, AWG22, drag-chain suitable

Beckhoff

ZK1090-6161-3xxx

EtherCAT cable, PVC, AWG26, fixed installation

Beckhoff

ZK1090-6161-4xxx

EtherCAT cable, PUR, AWG26, drag-chain suitable

Beckhoff

ZK1090-6162-0xxx

EtherCAT cable, PUR, AWG22, drag-chain suitable

Beckhoff

ZK1090-6163-0xxx

EtherCAT cable, PUR, AWG22, drag-chain suitable

Beckhoff

ZK1090-6166-0xxx

EtherCAT cable, PUR, AWG22, drag-chain suitable

Beckhoff

ZK1090-6191-0xxx

EtherCAT cable, PUR, AWG22, drag-chain suitable

Beckhoff

ZK1090-6191-3xxx

EtherCAT cable, PVC, AWG26, fixed installation

Beckhoff

ZK1090-6191-4xxx

EtherCAT cable, PUR, AWG26, drag-chain suitable

Beckhoff

ZK1090-6291-0xxx

EtherCAT cable, PUR, AWG22, drag-chain suitable

Beckhoff

ZK1090-6292-0xxx

EtherCAT cable, PUR, AWG22, drag-chain suitable

Beckhoff

ZK1090-6292-3xxx

EtherCAT cable, PVC, AWG26, fixed installation

Beckhoff

ZK1090-6292-4xxx

EtherCAT cable, PUR, AWG26, drag-chain suitable

Beckhoff

ZK1090-6300-0xxx

EtherCAT cable, PUR, AWG22, drag-chain suitable

Beckhoff

ZK1090-6332-0xxx

EtherCAT cable, PUR, AWG22, drag-chain suitable

Beckhoff

ZK1090-6363-0xxx

EtherCAT cable, PUR, AWG22, drag-chain suitable

Beckhoff

ZK1090-6366-0xxx

EtherCAT cable, PUR, AWG22, drag-chain suitable

Compare EtherCAT and fieldbus cables

Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.

MPN	Installation size	Rated voltage	A1	A2	B1
ZK1090-3332-0xxx	M8	30 V (according to IEC 61076-2-104)	29.80 mm	26.30 mm	40.00 mm
ZK1090-3333-0xxx	M8	30 V (according to IEC 61076-2-104)	29.80 mm	26.30 mm	29.80 mm
ZK1090-3363-0xxx	M12	160 V (according to IEC 61076-2-101)	29.80 mm	26.30 mm	35.30 mm
ZK1090-3391-0xxx	RJ45	125 V	29.80 mm	26.30 mm	44.0 mm
ZK1090-3891-0xxx	RJ45	125 V	34.50 mm	M12	44.0 mm
ZK1090-6100-0xxx	open end	160 V (according to IEC 61076-2-101)	49.00 mm	Ø14.50 mm	—
ZK1090-6100-4xxx	open end	160 V (according to IEC 61076-2-101)	49.00 mm	Ø14.50 mm	—
ZK1090-6161-0xxx	M12	160 V (according to IEC 61076-2-101)	49.00 mm	Ø14.50 mm	49.00 mm
ZK1090-6161-3xxx	M12	160 V (according to IEC 61076-2-101)	49.00 mm	Ø14.50 mm	49.00 mm
ZK1090-6161-4xxx	M12	160 V (according to IEC 61076-2-101)	49.00 mm	Ø14.50 mm	49.00 mm
ZK1090-6162-0xxx	M12	160 V (according to IEC 61076-2-101)	49.00 mm	Ø14.50 mm	43.00 mm
ZK1090-6163-0xxx	M12	160 V (according to IEC 61076-2-101)	49.00 mm	Ø14.50 mm	35.30 mm
ZK1090-6166-0xxx	M12	160 V (according to IEC 61076-2-101)	49.00 mm	Ø14.50 mm	43.00 mm
ZK1090-6191-0xxx	RJ45	150 V	49.00 mm	Ø14.50 mm	43.80 mm
ZK1090-6191-3xxx	RJ45	125 V	49.00 mm	Ø14.50 mm	44.0 mm
ZK1090-6191-4xxx	RJ45	125 V	49.00 mm	Ø14.50 mm	44.0 mm
ZK1090-6291-0xxx	RJ45	150 V	43.00 mm	M16	43.80 mm
ZK1090-6292-0xxx	RJ45	160 V	43.00 mm	M12 inner diameter, M16 outer diameter	37.00 mm
ZK1090-6292-3xxx	RJ45	125 V	43.00 mm	M12 inner diameter, M16 outer diameter	44.0 mm
ZK1090-6292-4xxx	RJ45	125 V	43.00 mm	M12 inner diameter, M16 outer diameter	44.0 mm
ZK1090-6300-0xxx	open end	160 V (according to IEC 61076-2-101)	35.30 mm	32.50 mm	—
ZK1090-6332-0xxx	M8	30 V (according to IEC 61076-2-104)	35.30 mm	32.50 mm	40.00 mm
ZK1090-6363-0xxx	M12	160 V (according to IEC 61076-2-101)	35.30 mm	32.50 mm	35.30 mm
ZK1090-6366-0xxx	M12	160 V (according to IEC 61076-2-101)	35.30 mm	32.50 mm	43.00 mm

Common to all listed parts

Shielding

yes
