Linear bushings Parts
























Compare Linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Dynamic load capacity C [N] | Dynamic torsional moment load capacity Mt [Nm] | Length of linear bushing [mm] | Weight [kg] |
|---|---|---|---|---|---|
| R072033000 | 30.0 | 3680.0 | 37.0 | 68.0 | 0.22 |
| R072032579 | 25.0 | 3030.0 | 24.0 | 58.0 | 0 |
| R072032589 | 25.0 | 3030.0 | 24.0 | 58.0 | 0 |
| R072032585 | 25.0 | 3030.0 | 24.0 | 58.0 | 3.6 |
| R072032580 | 25.0 | 3030.0 | 24.0 | 58.0 | 2.08 |
| R072032588 | 25.0 | 3030.0 | 24.0 | 58.0 | 0.1 |
| R072032587 | 25.0 | 3030.0 | 24.0 | 58.0 | 0.1 |
| R072032569 | 25.0 | 3030.0 | 24.0 | 58.0 | 0 |
| R072032586 | 25.0 | 3030.0 | 24.0 | 58.0 | 0 |
| R072032500 | 25.0 | 3030.0 | 24.0 | 58.0 | 0.15 |
| R072032079 | 20.0 | 1550.0 | 12.0 | 45.0 | 0 |
| R072032089 | 20.0 | 1550.0 | 12.0 | 45.0 | 0 |
| R072032085 | 20.0 | 1550.0 | 12.0 | 45.0 | 2.45 |
| R072032080 | 20.0 | 1550.0 | 12.0 | 45.0 | 1.32 |
| R072032088 | 20.0 | 1550.0 | 12.0 | 45.0 | 0.01 |
| R072032087 | 20.0 | 1550.0 | 12.0 | 45.0 | 3.1 |
| R072032086 | 20.0 | 1550.0 | 12.0 | 45.0 | 0 |
| R072032000 | 20.0 | 1550.0 | 12.0 | 45.0 | 0.09 |
| R072001679 | 16.0 | 780.0 | 3.3 | 36.0 | 0 |
| R072001689 | 16.0 | 780.0 | 3.3 | 36.0 | 0 |
| R072001685 | 16.0 | 780.0 | 3.3 | 36.0 | 1.5 |
| R072001680 | 16.0 | 780.0 | 3.3 | 36.0 | 0.68 |
| R072001688 | 16.0 | 780.0 | 3.3 | 36.0 | 0.1 |
| R072001686 | 16.0 | 780.0 | 3.3 | 36.0 | 0 |
Common to all listed parts
| Version | Standard |
| Format of linear bushings | – Closed |
| Series | Torque-resistant compact |
| Type | Linear bushing |
| Seal | Without wiper seals |
| Maximum acceleration rate amax [m/s²] | 150.0 |
| Maximum permissible linear speed vmax [m/s] | 3.0 |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
