Linear bushings Parts
Compare Linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Dynamic load capacity C [N] | Dynamic torsional moment load capacity Mt [Nm] | Length of linear bushing [mm] | Weight [kg] |
|---|---|---|---|---|---|
| R072035079 | 50.0 | 9250.0 | 167.0 | 100.0 | 0 |
| R072035089 | 50.0 | 9250.0 | 167.0 | 100.0 | 0 |
| R072035085 | 50.0 | 9250.0 | 167.0 | 100.0 | 15 |
| R072035080 | 50.0 | 9250.0 | 167.0 | 100.0 | 0.67 |
| R072035087 | 50.0 | 9250.0 | 167.0 | 100.0 | 21 |
| R072035069 | 50.0 | 9250.0 | 167.0 | 100.0 | 0 |
| R072035086 | 50.0 | 9250.0 | 167.0 | 100.0 | 0 |
| R072035000 | 50.0 | 9250.0 | 167.0 | 100.0 | 0.67 |
| R072034079 | 40.0 | 6320.0 | 86.0 | 80.0 | 0 |
| R072034089 | 40.0 | 6320.0 | 86.0 | 80.0 | 0 |
| R072034085 | 40.0 | 6320.0 | 86.0 | 80.0 | 10.31 |
| R072034080 | 40.0 | 6320.0 | 86.0 | 80.0 | 0.1 |
| R072034087 | 40.0 | 6320.0 | 86.0 | 80.0 | 0.1 |
| R072034069 | 40.0 | 6320.0 | 86.0 | 80.0 | 0 |
| R072034086 | 40.0 | 6320.0 | 86.0 | 80.0 | 0 |
| R072034000 | 40.0 | 6320.0 | 86.0 | 80.0 | 0.39 |
| R072033079 | 30.0 | 3680.0 | 37.0 | 68.0 | 0 |
| R072033089 | 30.0 | 3680.0 | 37.0 | 68.0 | 0 |
| R072033085 | 30.0 | 3680.0 | 37.0 | 68.0 | 5.9 |
| R072033080 | 30.0 | 3680.0 | 37.0 | 68.0 | 4.45 |
| R072033088 | 30.0 | 3680.0 | 37.0 | 68.0 | 11.2 |
| R072033087 | 30.0 | 3680.0 | 37.0 | 68.0 | 0.1 |
| R072033069 | 30.0 | 3680.0 | 37.0 | 68.0 | 0 |
| R072033086 | 30.0 | 3680.0 | 37.0 | 68.0 | 0 |
Common to all listed parts
| Version | Standard |
| Format of linear bushings | – Closed |
| Series | Torque-resistant compact |
| Type | Linear bushing |
| Seal | Without wiper seals |
| Raceway grooves | 2 |
| Maximum acceleration rate amax [m/s²] | 150.0 |
| Maximum permissible linear speed vmax [m/s] | 3.0 |
