Schneider Electric VZN30
TeSys Mini-VARIO and VARIO - shaft extension - for V02...V2 / VN12 / VN20
- MPN
- VZN30
- EAN
- 3389110787245
- Category
- TeSys Vario
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the Schneider Electric VZN30?
TeSys Vario shaft extension, for TeSys mini-Vario switch bodies VN12 and VN20. It allows the operation of a switch body located on the back of enclosure with a door-mounted handle. Possible distance between back of enclosure and door 300-330mm. Green Premium compliant (RoHS/REACh).
Specifications
Specifications
| Range | TeSys |
| Device short name | VZ |
| Product or component type | Shaft extension |
| Accessory / separate part category | Locking accessory |
| Product compatibility | VN12, V02...V2, VN20 |
| Mechanical interlocking | Door interlocking function |
| Back/door distance | 400…430 mm |
| Length | 400 mm |
| Cross-section height | 6 mm |
| Cross-section width | 6 mm |
| Net weight | 130 g |
Packaging
| Package 1 | 1 PCE, 36.200 cm × 7.800 cm × 2.700 cm (L × W × H), 129.000 g |
| Package 2 | 25 S02, 40.000 cm × 30.000 cm × 15.000 cm (L × W × H), 3.574 kg |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
VZN30: frequently asked questions
When can VZN30 be shipped?
VZN30 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up VZN30 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for VZN30 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for VZN30, subject to availability and destination.
