PanelSeT S3D seismic plain door with mount.plate - H700xW500xD250 - IP65 - IK10
MPN: NSYS3D6G7525P · Brand: Schneider Electric
Price on request
Request a Quote
12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
Quick facts
| Availability | Confirmed on request |
| Category | PanelSeT S3D |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 33 kg |
Shipping & availability
When can NSYS3D6G7525P be shipped?
NSYS3D6G7525P is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up NSYS3D6G7525P in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for NSYS3D6G7525P and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for NSYS3D6G7525P, subject to availability and destination.
Specifications
Specifications
| Range | PanelSeT |
| Product name | S3D 6G |
| Enclosure application | Seismic |
| Product or component type | Enclosure |
| Enclosure nominal height | 700 mm |
| Enclosure nominal width | 500 mm |
| Enclosure nominal depth | 250 mm |
| Door type | Plain |
| Mounting plate description | Reinforce |
| Enclosure mounting | Wall mounted |
| Device composition | 1 x body, 1 x door, 1 x lock, 2 x fixing bracket, 1 x mounting plate, 1 x earthing components door and lock, 1 x cable gland plate |
| Continuity of earth | Earthing connection between body and door |
| Body type | Single piece body, Gutter-shaped front rail |
| Number of doors | Front face: 1 door(s) |
| Door opening side | Right (120 °) |
| Lock type | 3-point closure |
| Type of keylock | 405E |
| Type of operating handle | Swing handle |
| Accessibility for operation | Front |
| Removable parts | Cable gland plate by screws |
| Material | Steel |
| Thickness | Body: 2 mm, Door: 2 mm, Cable gland plate: 1.5 mm |
| Surface finish | Epoxy-polyester powder |
| Colour | Grey (RAL 7035) |
| Net weight | 33 kg |
| Surface treatment | 87 % decontaminable painting conforming to NF T 30-501. |
| Standards | IEC 62208, EDF CRT 91 C 112 00 |
| IP degree of protection | IP65 conforming to IEC 60529 |
| IK degree of protection | IK10 conforming to IEC 62262 |
| Seismic performance | Seismic tests 6G conforming to EDF CRT 91 C 112 00 |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 30.000 cm |
| Package 1 Width | 53.000 cm |
| Package 1 Length | 78.000 cm |
| Package 1 Weight | 34.000 kg |
| Unit Type of Package 2 | PAM |
| Number of Units in Package 2 | 5 |
| Package 2 Height | 98.000 cm |
| Package 2 Width | 100.000 cm |
| Package 2 Length | 120.000 cm |
| Package 2 Weight | 182.000 kg |
| Coverage | Core product |
| Warranty | 18 months |
