Schneider Electric NSYMM25SB
Plain mounting plate H200xW500mm made of galvanised sheet steel
- MPN
- NSYMM25SB
- EAN
- 3606480520570
- Category
- PanelSeT SBM
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the Schneider Electric NSYMM25SB?
Schneider Electric Plain mounting plate H200xW500mm made of galvanised sheet steel, manufacturer part number NSYMM25SB. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Range | PanelSeT |
| Accessory / separate part category | Mounting accessory |
| Product or component type | Mounting plate |
| Device application | Multi-purpose |
| Enclosure nominal dimensions | - |
| Mounting location | Bottom of enclosure |
| Mounting plate description | Plain |
| Range compatibility | PanelSeT SBM |
| Device composition | 1 mounting plate |
| Material | Galvanised steel |
| Surface finish | Metallic |
| Fixing mode | By 2 screws - screw type Ø5 mm self-tapping screws - bottom of enclosure location |
| Permanent permissible load | 5 kg back of the enclosure |
| Height | Nominal: 175 mm |
| Width | Nominal: 485 mm, Fixing centers: 464 mm |
| Surface and useful surface | Nominal: 100000 mm² |
| thickness | 2 mm |
| Net weight | 1.287 kg |
Packaging
| Package 1 | 1 PCE, 0.300 cm × 18.000 cm × 49.000 cm (L × W × H), 1.302 kg |
| Package 2 | 300 PAM, 120.000 cm × 100.000 cm × 45.000 cm (L × W × H), 404.000 kg |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
NSYMM25SB: frequently asked questions
When can NSYMM25SB be shipped?
NSYMM25SB is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up NSYMM25SB in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for NSYMM25SB and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for NSYMM25SB, subject to availability and destination.
