Schneider Electric ABR7S11
Plug-in electromechanical relay - 5 mm - 24 V DC - 1 NO
- MPN
- ABR7S11
- EAN
- 3389110251470
- Category
- Modicon ABE7
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the Schneider Electric ABR7S11?
"This product is part of the Modicon ABE7 range, an offer of connection sub-bases for pre-wired system." "This is an electromechanical plug-in relays for 24VDC prewired sub-bases." "It has 1 NO contact. Its mechanical durability is up to 20000000 cycles. It immunity to microbreaks is up to 1ms." "It is used to to control the power along with switching the smaller current values in a control circuit." "It is 5mm wide." "It weighs 0.005kg." "It is suitable into any types of industrial applications needing rapid connection of I/O modules (digital, analog, and counter) to operative parts." "It is suitable for use with ABE7R16T111, ABE7R16M111, ABE7P16M111, and ABE7P16T111 sub-bases." "It is delivered in 1 package (PCE type) containing 4 units." "Modicon ABE7 means greater simplicity to rationalise wiring in automation system equipment."
Specifications
Specifications
| Range of product | Advantys Telefast ABE7 |
| Product or component type | Plug-in electromechanical relay |
| Control circuit type | DC |
| minimum ordered quantity | Set of 4 |
| Width pitch dimension | 5 mm |
| Product compatibility | ABE7R16T111, ABE7R16M111, ABE7P16M111, ABE7P16T111 |
| [Uc] control circuit voltage | 24 V |
| [Ith] conventional free air thermal current | 6 A |
| Contacts type and composition | 1 NO |
| Threshold tripping voltage | 16.8 V at 40 °C |
| Drop-out voltage | 2 V at 20 °C |
| Drop-out current | 0.5 mA at 20 °C |
| Maximum power dissipation per pole | 0.17 W |
| Associated fuse rating | 1 A, fast blow |
| Maximum switching voltage | 250 V AC 50/60 Hz conforming to IEC 60947-5-1, 30 V DC conforming to IEC 60947-5-1 |
| Electrical durability | 500000 cycles, maximum switching current: 2000 mA at 230 V AC-12, 500000 cycles, maximum switching current: 3000 mA at 24 V DC-12, 500000 cycles, maximum switching current: 400 mA at 230 V AC-15, 500000 cycles, maximum switching current: 500 mA at 24 V DC-13 10 ms |
| Minimum switching current | 100 mA at >= 5 V |
| Operating rate in Hz | 20 Hz no load, 0.1 Hz at Ie |
| Mechanical durability | 20000000 cycles |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-1 |
| Net weight | 0.005 kg |
| Max immunity to microbreaks | 1 ms |
| Dielectric strength | 4000 V conforming to IEC 60947-1 |
Packaging
| Package 1 | 1 PCE, 15 cm × 2.4 cm × 0.8 cm (L × W × H), 5 g |
| Package 2 | 4 BB1, 15 cm × 2.4 cm × 0.8 cm (L × W × H), 29 g |
| Package 3 | 200 S01, 40 cm × 15 cm × 15 cm (L × W × H), 1.65 kg |
