Danfoss FCZ1003

HOSE-AER, FCZ, -10, 3FT, RL, PRFM,GY

MPN: FCZ1003
Category: Aeroquip performance products

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Danfoss FCZ1003?

Danfoss HOSE-AER, FCZ, -10, 3FT, RL, PRFM,GY, manufacturer part number FCZ1003. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146212825
Abrasion resistance	Premium
Application	Air conditioning
Bend radius min (inch)	3.000
Bend radius min (mm)	76.200
Brand	Aeroquip by Danfoss
Burst pressure (bar)	140
Burst pressure (psi)	2000
Color	Stainless steel
Compliances	SAE J3062 Type C Class I
Conductivity	Conductive
Construction	1 Ply braid
Cover material	EPDM
Inside diameter (inch)	0.53
Inside diameter (mm)	13.50
Lay line style	Transfer tape
Length (in)	36.00000
Length (mm)	914.40000
Outside diameter (inch)	0.80
Outside diameter (mm)	20.32
Package form	Reel
Product height in	0.530
Product height mm	13.500
Product width in	0.530
Product width mm	13.500 mm
Qualified hose fittings	A/C fittings
Reinforcement material	Fabric
Series	FCZ Series
Size	-10
Tube material	Polyamide (PA)
Tube wall thickness (inch)	0.06
Tube wall thickness (mm)	1.40
Working pressure max (bar)	35
Working pressure max (psi)	500
Working temperature max (C)	140
Working temperature max (F)	284.0
Working temperature min (C)	-40
Working temperature min (F)	-40.0
