Danfoss FCZ0803

HOSE-AER, FCZ, -8, 3FT, RL, PRFM,GY

MPN: FCZ0803
Category: Aeroquip performance products

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Danfoss FCZ0803?

Danfoss HOSE-AER, FCZ, -8, 3FT, RL, PRFM,GY, manufacturer part number FCZ0803. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146212795
Abrasion resistance	Premium
Application	Air conditioning
Bend radius min (inch)	2.500
Bend radius min (mm)	63.500
Brand	Aeroquip by Danfoss
Burst pressure (bar)	140
Burst pressure (psi)	2000
Color	Stainless steel
Compliances	SAE J3062 Type C Class I
Conductivity	Conductive
Construction	1 Ply braid
Cover material	EPDM
Inside diameter (inch)	0.42
Inside diameter (mm)	10.70
Lay line style	Transfer tape
Length (in)	36.00000
Length (mm)	914.40000
Outside diameter (inch)	0.70
Outside diameter (mm)	17.78
Package form	Reel
Product height in	0.420
Product height mm	10.700
Product width in	0.420
Product width mm	10.700 mm
Qualified hose fittings	A/C fittings
Reinforcement material	Fabric
Series	FCZ Series
Size	-8
Tube material	Polyamide (PA)
Tube wall thickness (inch)	0.06
Tube wall thickness (mm)	1.40
Working pressure max (bar)	35
Working pressure max (psi)	500
Working temperature max (C)	140
Working temperature max (F)	284.0
Working temperature min (C)	-40
Working temperature min (F)	-40.0

FCZ0803: frequently asked questions

When can FCZ0803 be shipped?

FCZ0803 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up FCZ0803 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for FCZ0803 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for FCZ0803, subject to availability and destination.
