Danfoss 83145041

EHI STEERING VALVE

MPN: 83145041
Category: Electrohydraulic steering valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Danfoss 83145041?

Danfoss EHI STEERING VALVE, manufacturer part number 83145041. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Product type	EHi
Electrohydraulic flow, nominal	70 L/min
Circuit type	Load sense dynamic
Pilot unit type	Reaction
Disengage	Electric
LS1 signal (external)	Static
Integrated priority valve	For system with nominal pump flow above 45 l/min
Excess flow	Excess flow available
Integrated priority valve type	Dynamic
Integrated priority valve spring	7 bar spring
Pressure resolver (PVFC)	Without check valves
Relief valve connection	Build-in relief valve will limit steering pressures while steering withEHi as well as with pilot unit.
Ports standard	ISO 6149-1
Ports size	P,T,EF: M22CL,CR,L,R,CF: M18LS1,LS2: M18if machined
LS1 port	Steel plug
LS2 port	Plastic plug
EF port	Plastic plug
P and T front ports	Plastic plugs
P and T side ports	Steel plugs
CL and CR ports	Plastic plugs
L and R ports	Plastic plugs
CF port	Steel plug
PVE actuator	PVED-CLS s5 Deutsch (SIL2)
Firmware version	Standard
Firmware revision	2.21
Firmware package	Not applicable
Additional information	No additional info
Cut off connector	Deutsch
Cut off coil voltage	12 VDC
Relief valve setting	190-200 Bar
Shock valve setting	280-308 bar
Dynamic orifice	Regular. 0.9 mm dyn. orifice
PP orifice	Regular. 0.7 mm PP orifice
LS orifice	Regular. 1.2 mm LS orifice
Reaction Switch	Choose this option if orbital displacement is higher than 300 cc/rev
Special feature	No special feature
Paint	Painted black
Software ID	SWID071627
Housing variant	EHI-5 (ISO)
Label	Danfoss Standard Label
Proposition 65	Cancer and Reproductive Harm
