Balluff BOS00Y8
BOS Q08M-PO-KE20-00,2-S49 – Through-beam sensors
- MPN
- BOS00Y8
- Category
- Through-beam sensors
Price and lead time confirmed within 1 business day
Discontinued by Balluff — we can still source the original BOS00Y8 (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Balluff BOS00Y8?
Balluff BOS00Y8 (BOS Q08M-PO-KE20-00,2-S49) — Through-beam sensor. Series: Q08M; Dimension: 8 x 44 x 8 mm; Interface: PNP normally closed (NC); Principle of optical operation: Through-beam sensor (receiver); Light type: Red light. Discontinued by Balluff; Balluff names BOS01Y9 as alternative. PartnerPLC supplies new, surplus and discontinued Balluff parts — request a quote for price, condition and lead time.
Specifications
Product
| Lifecycle | Discontinued by Balluff |
| Type designation | BOS Q08M-PO-KE20-00,2-S49 |
| Product group | Through-beam sensors |
| Balluff alternatives | BOS01Y9 |
Key features
| Series | Q08M |
| Dimension | 8 x 44 x 8 mm |
| Interface | PNP normally closed (NC) |
| Principle of operation | Photoelectric sensor |
| Principle of optical operation | Through-beam sensor (receiver) |
| Light type | Red light |
| Range | 0...2.2 m |
| Connection | Cable with connector, M8x1-Male, 3-pin, 0.20 m, PUR |
| Housing material | Zinc, Die casting, nickel-plated |
| Material sensing surface | PMMA |
| Operating voltage Ub | 10...30 VDC |
| Approval/Conformity | cULus CE EAC |
Classifications
| ECLASS 14.0 | 27-27-09-01 |
| ETIM 9.0 | EC002716 |
| UNSPSC 11 | 39121528 |
No matching specifications
BOS00Y8: frequently asked questions
Can I still buy the BOS00Y8 now that it is discontinued?
Yes. Balluff has discontinued the BOS00Y8, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Balluff names the BOS01Y9 as its successor — we can quote both.
When can BOS00Y8 be shipped?
BOS00Y8 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up BOS00Y8 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for BOS00Y8 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BOS00Y8, subject to availability and destination.
