ABB ACS310-01U-04A7-2

LV AC drive module for pumps and fans, IEC: Pn 1 Hp, 4.7 A ( )

MPN: ACS310-01U-04A7-2
Category: ACS310

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the ABB ACS310-01U-04A7-2?

The ACS310 drives are designed for variable torque applications such as booster pumps and supply and return fans. The drive includes a powerful and beneficial set of features designed for pump and fan applications. These features include built-in PID controllers and pump and fan control (PFC) that varies the drive’s performance in response to changes in pressure, flow or other external data.

Specifications

Ordering

Customs Tariff Number	85044084
HS Code	850440 -- ELECTRICAL MACHINERY AND EQUIPMENT AND PARTS THEREOF; SOUND RECORDERS AND REPRODUCERS, TELEVISION IMAGE AND SOUND RECORDERS AND REPRODUCERS, AND PARTS AND ACCESSORIES OF SUCH ARTICLES;Electrical transformers, static converters (for example, rectifiers) and inductors;Static converters
Invoice Description	ACS310-01U-04A7-2, 200 VAC, Pn 1HP , I2n 4.7A, IP20
Made To Order	No
Minimum Order Quantity	1 piece
Order Multiple	1 piece
Quote Only	No
Selling Unit of Measure	piece

Dimensions

Product Net Weight	3.1 lb
Product Net Depth / Length	6.34 in
Product Net Height	9.41 in
Product Net Width	2.76 in

Technical

Number of Phases	1-phase
Degree of Protection	IP20
Frequency (f)	50/60 Hz Hz
Frame Size	R1
Input Voltage (Uin)	200 ... 240 V V
Mounting Type	Wall-mounting
Output Current, Normal Use (In)	4.7 A A
Output Power, Normal Use (Pn)	1 Hp
Ecodesign Exemption	Energy efficiency data is not provided for the 1~230 V drives. The drives with one phase input are not in the scope of the EU ecodesign requirements (Regulation EU/2019/1781). V

Environmental

SCIP	19e91ffb-1eea-4f03-8e25-25819ab6b3bf Finland
WEEE Category	5. Small Equipment (No External Dimension More Than 50 cm) cm

External Classifications and Standards

eClass	ETIM 7
UNSPSC	39122001
