Radial piston pumps Parts
Compare Radial piston pumps
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Connection diagram | Size [cm³] | Operating pressure, max. [bar] | Max. flow [l/min] | Weight [kg] |
|---|---|---|---|---|---|
| R901088867 | 1 | 6.3 | 500.0 | 7.5 | 9.24 |
| R901092566 | — | 5 | 700.0 | 10.0 | 16.64 |
| R901092556 | — | 5 | 700.0 | 10.0 | 16.3 |
| R901092497 | 1 | 2.5 | 700.0 | 3.5 | 16.45 |
| R901453559 | 2 | 5 | 500.0 | 6.0 | 9.76 |
| R901485284 | 3 | 5 | 500.0 | 6.0 | 10 |
| R901089883 | 1 | 5 | 500.0 | 6.0 | 9.76 |
| R901089766 | 1 | 5 | 500.0 | 6.0 | 6.81 |
| R901089764 | 1 | 5 | 500.0 | 6.0 | 8.86 |
| R901093645 | 2 | 5 | 500.0 | 6.0 | 9.18 |
| R901093643 | 1 | 5 | 500.0 | 6.0 | 9.11 |
| R901192008 | 3 | 5 | 500.0 | 6.0 | 6.81 |
| R901535694 | 1 | 5 | 500.0 | 6.0 | 12.3 |
| R901106349 | 1 | 5 | 500.0 | 6.0 | 8.92 |
| R901088770 | 3 | 5 | 500.0 | 6.0 | 8.92 |
| R901088758 | 2 | 5 | 500.0 | 6.0 | 8.88 |
| R901501600 | 1 | 5 | 500.0 | 6.0 | 8.82 |
| R901088695 | 1 | 5 | 500.0 | 6.0 | 9.08 |
| R901480148 | 5 | 4 | 700.0 | 5.5 | 11.83 |
| R901089882 | 1 | 4 | 700.0 | 5.5 | 12.1 |
| R901089735 | 1 | 4 | 700.0 | 5.5 | 10.94 |
| R901374925 | 5 | 4 | 700.0 | 5.5 | 10.8 |
| R901089733 | 1 | 4 | 700.0 | 5.5 | 10.5 |
| R901093868 | 1 | 4 | 700.0 | 5.5 | 11.02 |
Common to all listed parts
| Displacement type | constant |
| Product family | PR4 |
| Direction of rotation | clockwise rotation |
| Mounting flange | 4-hole fastening centering 63 mm |
