Wall mounting Parts
Compare Wall mounting
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Number of slots | Weight |
|---|---|---|
| 8B0M0020HW00.000-1 | 2 | 1.05 kg |
| 8B0M0030HW00.000-1 | 3 | 1.6 kg |
| 8B0M0040HW00.000-1 | 4 | 2.1 kg |
| 8B0M0050HW00.000-1 | 5 | 2.7 kg |
| 8B0M0060HW00.000-1 | 6 | 3.2 kg |
| 8B0M0070HW00.000-1 | 7 | 3.7 kg |
| 8B0M0080HW00.000-1 | 8 | 4.2 kg |
| 8B0M0090HW00.000-1 | 9 | 4.8 kg |
| 8B0M0100HW00.000-1 | 10 | 5.3 kg |
| 8B0M0110HW00.000-1 | 11 | 5.8 kg |
| 8B0M0120HW00.000-1 | 12 | 6.4 kg |
| 8B0M0130HW00.000-1 | 13 | 6.9 kg |
| 8B0M0140HW00.000-1 | 14 | 7.4 kg |
| 8B0M0150HW00.000-1 | 15 | 8 kg |
| 8B0M0160HW00.000-1 | 16 | 8.5 kg |
| 8B0M0170HW00.000-1 | 17 | 9 kg |
| 8B0M0180HW00.000-1 | 18 | 9.5 kg |
| 8B0M0190HW00.000-1 | 19 | 10.1 kg |
| 8B0M0200HW00.000-1 | 20 | 10.6 kg |
| 8B0M0210HW00.000-1 | 21 | 11.1 kg |
| 8B0M0220HW00.000-1 | 22 | 11.7 kg |
| 8B0M0230HW00.000-1 | 23 | 12.2 kg |
| 8B0M0240HW00.000-1 | 24 | 12.7 kg |
| 8B0M0250HW00.000-1 | 25 | 13.3 kg |
Common to all listed parts
| Certifications – CE | Yes |
| Certifications – UKCA | Yes |
| Certifications – CRA (Cyber Resilience Act) | Not applicable |
| Certifications – UL | cULus E225616; Power conversion equipment |
| Cooling and mounting type | Wall mounting |
| Voltage – Nominal | 750 VDC |
| Reduction of continuous power depending on installation elevation – Starting at 500 m above sea level | 20 kW per 1000 m |
| Cross section – DC+, DC- | 72 mm² |
