Schneider Electric
RE22R2QGMRSingle function relay, Harmony Timer Relays, 8A, 2CO, 0.05s…300h, star delta, 24...240V AC DC
Harmony Timer Relays Parts
Schneider Electric
RE22R2QEMTSingle function relay, Harmony Timer Relays, 8A, 2CO, 0.3...30s, star delta, 380...415V AC DC
Schneider Electric
RE22R2QEMRSingle function relay, Harmony Timer Relays, 8A, 2CO, 0.3s…30s, star delta, 24...240V AC DC
Schneider Electric
RE22R2MYMRMultifunction relay, Harmony Timer Relays, 8A, 2CO, 0.05s…300h, screw connectors, 24...240V AC DC
Schneider Electric
RE22R2MXMUMultifunction relay, Harmony Timer Relays, 8A, 2CO, 0.1s…100h, bistable, 24V DC or 24...240V AC DC
Schneider Electric
RE22R2MWMRSingle function relay, Harmony Timer Relays, 8A, 2CO, 0.05s...300h, interval relay, 24...240V AC DC
Schneider Electric
RE22R2MMWMultifunction relay, Harmony Timer Relays, 8A, 2CO, 0.1s…100h, symmetrical flashing, 12..240V AC DC
Schneider Electric
RE22R2MMUMultifunction relay, Harmony Timer Relays, 8A, 2CO, 0.1s…100h, 24V DC or 24...240V AC DC
Schneider Electric
RE22R2MJUSingle function relay, Harmony Timer Relays, 8A, 2CO, 0.1s…100h, multifunction, 12V AC DC
Schneider Electric
RE22R2KMRSingle function relay, Harmony Timer Relays, 5A, 2CO, 0.05s…10min, delay on de energization, 24...240V AC DC
Schneider Electric
RE22R2HMRDual function relay, Harmony Timer Relays, 8A, 2CO, 0.05s…300h, interval relay, 24...240V AC DC
Schneider Electric
RE22R2DMRSingle function relay, Harmony Timer Relays, 8A, 2CO, 0.05s...300h, symmetrical flashing, 24...240V AC DC
Schneider Electric
RE22R2CMRSingle function relay, Harmony Timer Relays, 8A, 2CO, 0.05s...300h, off delay, 24...240V AC DC
Schneider Electric
RE22R2AMUDual function relay, Harmony Timer Relays, 8A, 2CO, 0.1s…100h, power on delay, screw connectors, 24V DC or 24...240V AC DC
Schneider Electric
RE22R2AMRDual function relay, Harmony Timer Relays, 8A, 2CO, 0.05s…300h, power on delay, 24...240V AC DC
Schneider Electric
RE22R2ACMRSingle function relay, Harmony Timer Relays, 8A, 2CO, 0.05s…300h, on delay and off delay, 24...240V AC DC
Schneider Electric
RE22R1QMUSingle function relay, Harmony Timer Relays, 8A, 1CO, 0.1s…100h, star delta, 24V DC or 24...240V AC DC
Schneider Electric
RE22R1QMQSingle function relay, Harmony Timer Relays, 8A, 1CO, 0.05...300h, star delta, 230...440V AC
Schneider Electric
RE22R1QCMUSingle function relay, Harmony Timer Relays, 8A, 1 CO, 0.05s…300s, star delta, 24V DC or 24...240V AC DC
Schneider Electric
RE22R1MYMRMultifunction relay, Harmony Timer Relays, 8A, 1 CO, 0.05s…300h, symmetrical flashing, 24...240V AC DC
Schneider Electric
RE22R1MLMRMultifunction relay, Harmony Timer Relays, 8A, 1 CO, 0.05s…300h, asymmetrical flashing, 24...240V AC DC
Schneider Electric
RE22R1MKMRDual function relay, Harmony Timer Relays, 5A, 1 CO, 0.05s…300s, delay on and pulse on de energization, 24...240V AC DC
Schneider Electric
RE22R1MAMRMultifunction relay, Harmony Timer Relays, 8A, 1 CO, 0.05s…300h, on delay, 24...240V AC DC
Schneider Electric
RE22R1KMRSingle function relay, Harmony Timer Relays, 5A, 1 CO, 0.05s…10min, delay on de energization, 24...240V AC DC
Compare Harmony Timer Relays
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | [Us] rated supply voltage | Safety reliability data | Net weight | Number of functions | Product certifications |
|---|---|---|---|---|---|
| RE22R2QGMR | 24...240 V AC/DC 50/60 Hz | MTTFd = 342.4 years, B10d = 320000 | 0.105 kg | 1 | CCC, CSA, RCM, GL, EAC, CE, UL |
| RE22R2QEMT | 380...415 V AC 50/60 Hz | B10d = 250000, MTTFd = 273.9 years | 0.09 kg | 1 | EAC, GL, CSA, UL, CCC, RCM, CE |
| RE22R2QEMR | 24...240 V AC/DC 50/60 Hz | B10d = 320000, MTTFd = 353.8 years | 0.09 kg | 1 | CE, CSA, GL, EAC, UL, RCM, CCC |
| RE22R2MYMR | 24...240 V AC/DC 50/60 Hz | B10d = 160000, MTTFd = 171.2 years | 0.105 kg | 22 | RCM, CE, EAC, CSA, CCC, UL, GL |
| RE22R2MXMU | 24...240 V AC, 24 V DC | B10d = 170000, MTTFd = 182.6 years | 0.09 kg | 9 | CSA, CCC, GL, cULus, EAC, CE, RCM |
| RE22R2MWMR | 24...240 V AC/DC 50/60 Hz | B10d = 160000, MTTFd = 171.2 years | 0.105 kg | 2 | UL, GL, CE, CSA, RCM, EAC, CCC |
| RE22R2MMW | 12...240 V AC/DC | B10d = 230000, MTTFd = 251.1 years | 0.093 kg | 10 | CSA, CE, cULus, GL, RCM, CCC, EAC |
| RE22R2MMU | 24...240 V AC, 24 V DC | MTTFd = 182.6 years, B10d = 170000 | 0.09 kg | 10 | cULus, CSA, CE, CCC, RCM, GL, EAC |
| RE22R2MJU | 12 V AC/DC | B10d = 190000, MTTFd = 205.4 years | 0.09 kg | 10 | CSA, cULus, CE, EAC, GL, CCC, RCM |
| RE22R2KMR | 24...240 V AC/DC 50/60 Hz | B10d = 160000, MTTFd = 171.2 years | 0.1 kg | 1 | EAC, UL, RCM, GL, CCC, CSA, CE |
| RE22R2HMR | 24...240 V AC/DC 50/60 Hz | B10d = 200000, MTTFd = 216.8 years | 0.105 kg | 2 | RCM, CSA, CE, EAC, UL, CCC, GL |
| RE22R2DMR | 24...240 V AC/DC 50/60 Hz | B10d = 200000, MTTFd = 216.8 years | 0.105 kg | 2 | CCC, CSA, RCM, GL, CE, UL, EAC |
| RE22R2CMR | 24...240 V AC/DC 50/60 Hz | MTTFd = 251.1 years, B10d = 230000 | 0.105 kg | 1 | CSA, CCC, RCM, CE, GL, UL, EAC |
| RE22R2AMU | 24...240 V AC, 24 V DC | MTTFd = 182.6 years, B10d = 170000 | 0.09 kg | 2 | cULus, CE, EAC, CSA, RCM, CCC, GL |
| RE22R2AMR | 24...240 V AC/DC 50/60 Hz | B10d = 200000, MTTFd = 216.8 years | 0.105 kg | 2 | CE, CCC, GL, UL, RCM, EAC, CSA |
| RE22R2ACMR | 24...240 V AC/DC 50/60 Hz | MTTFd = 251.1 years, B10d = 230000 | 0.105 kg | 1 | RCM, CCC, CSA, UL, EAC, CE, GL |
| RE22R1QMU | 24...240 V AC, 24 V DC | MTTFd = 182.6 years, B10d = 170000 | 0.086 kg | 1 | CSA, EAC, RCM, CE, CCC, GL, cULus |
| RE22R1QMQ | 380...440 V AC, 230...240 V AC | B10d = 260000, MTTFd = 273.9 years | 0.093 kg | 1 | cULus, RCM, CSA, EAC, GL, CCC, CE |
| RE22R1QCMU | 24 V DC, 24...240 V AC 50/60 Hz | MTTFd = 285.3 years, B10d = 270000 | 0.08 kg | 1 | GL, CE, CCC, EAC, UL, CSA, RCM |
| RE22R1MYMR | 24...240 V AC/DC 50/60 Hz | MTTFd = 205.4 years, B10d = 190000 | 0.1 kg | 18 | RCM, GL, EAC, CE, CSA, CCC, UL |
| RE22R1MLMR | 24...240 V AC/DC 50/60 Hz | MTTFd = 194 years, B10d = 180000 | 0.1 kg | 4 | EAC, UL, GL, CSA, RCM, CCC, CE |
| RE22R1MKMR | 24...240 V AC/DC 50/60 Hz | B10d = 180000, MTTFd = 194 years | 0.1 kg | 2 | GL, UL, CSA, RCM, CCC, CE, EAC |
| RE22R1MAMR | 24...240 V AC/DC 50/60 Hz | B10d = 190000, MTTFd = 205.4 years | 0.1 kg | 3 | EAC, CSA, RCM, UL, GL, CE, CCC |
| RE22R1KMR | 24...240 V AC/DC 50/60 Hz | MTTFd = 194 years, B10d = 180000 | 0.1 kg | 1 | CCC, CSA, GL, RCM, CE, EAC, UL |
Common to all listed parts
| Range of product | Harmony Timer Relays |
| Discrete output type | Relay |
| Product or component type | Modular timing relay |
| Device short name | RE22 |
| Control type | With test button |
| Supply frequency | 50...60 Hz +/- 5 % |
| Tightening torque | 0.6…1 N.m conforming to IEC 60947-1 |
| Housing material | Polycarbonate |
