Linear bushings Parts
























Compare Linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Dynamic load capacity C [N] | Length of linear bushing [mm] | Outer diameter D [mm] | Weight [kg] |
|---|---|---|---|---|---|
| R069602087 | 20.0 | 1550.0 | 45.0 | 32.0 | 3.25 |
| R069602086 | 20.0 | 1550.0 | 45.0 | 32.0 | 0 |
| R069602000 | 20.0 | 1550.0 | 45.0 | 32.0 | 0.1 |
| R069601679 | 16.0 | 780.0 | 36.0 | 26.0 | 0 |
| R069601689 | 16.0 | 780.0 | 36.0 | 26.0 | 0 |
| R069601680 | 16.0 | 780.0 | 36.0 | 26.0 | 0.68 |
| R069601688 | 16.0 | 780.0 | 36.0 | 26.0 | 0.6 |
| R069601686 | 16.0 | 780.0 | 36.0 | 26.0 | 0 |
| R069601600 | 16.0 | 780.0 | 36.0 | 26.0 | 0.05 |
| R069601279 | 12.0 | 640.0 | 32.0 | 22.0 | 0 |
| R069601289 | 12.0 | 640.0 | 32.0 | 22.0 | 0 |
| R069601285 | 12.0 | 640.0 | 32.0 | 22.0 | 0.85 |
| R069601280 | 12.0 | 640.0 | 32.0 | 22.0 | 0.4 |
| R069601288 | 12.0 | 640.0 | 32.0 | 22.0 | 0.89 |
| R069601286 | 12.0 | 640.0 | 32.0 | 22.0 | 0 |
| R069601200 | 12.0 | 640.0 | 32.0 | 22.0 | 0.05 |
| R073125045 | 50.0 | 22300.0 | 100.0 | 75.0 | 0.87 |
| R073125040 | 50.0 | 22300.0 | 100.0 | 75.0 | 0.87 |
| R073115040 | 50.0 | 22300.0 | 100.0 | 75.0 | 0.87 |
| R073105000 | 50.0 | 22300.0 | 100.0 | 75.0 | 0.86 |
| R073124045 | 40.0 | 13500.0 | 80.0 | 62.0 | 0.5 |
| R073124040 | 40.0 | 13500.0 | 80.0 | 62.0 | 0.5 |
| R073114040 | 40.0 | 13500.0 | 80.0 | 62.0 | 0.51 |
| R073104000 | 40.0 | 13500.0 | 80.0 | 62.0 | 0.5 |
Common to all listed parts
| Version | Standard |
| Type | Linear bushing |
| Maximum acceleration rate amax [m/s²] | 150.0 |
