Bearings with adjusting screws Parts
Compare Bearings with adjusting screws
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Length of runner block [mm] | Maximum permissible dynamic torsional moment about the y-axis My max [Nm] | Maximum permissible dynamic torsional moment about the z-axis Mz max [Nm] | Weight [kg] | Dimension B (profiled rail systems) [mm] |
|---|---|---|---|---|---|
| R190335210 | 123.5 | 2,4 · b | 4 · b | 0.67 | 123.5 |
| R190315210 | 104.0 | 0,75· b | 1,2 · b | 0.38 | 104 |
| R190325210 | 118.5 | 1,2 · b | 2,2 · b | 0.56 | 118.5 |
| R190313210 | 87.0 | 0,42 · b | 0,5 · b | 0.16 | 87 |
| R190435210 | 194.5 | 194 | 324 | 1.05 | 194.5 |
| R190415210 | 159.0 | 49 | 83 | 0.58 | 159 |
| R190425210 | 184.5 | 91 | 171 | 0.88 | 184.5 |
| R190413210 | 129.0 | 21 | 25 | 0.23 | 129 |
Common to all listed parts
| Version | Cam roller guide |
| Maximum acceleration rate amax [m/s²] | 50.0 |
| Maximum permissible linear speed vmax [m/s] | 10.0 |
| Note: maximum permissible speed vmax | For average load. |
| Operating temperature (min. … max.) | -20 °C ... +80 °C |
| Maximum operating temperature [°C] | +80 |
| Minimum operating temperature [°C] | -20 |
| Dimension A2 (profiled rail systems) [mm] | 2 |
