High-precision ball runner block BSHP Parts
Compare High-precision ball runner block BSHP
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Width of runner block [mm] | Weight [kg] | Dimension A (profiled rail systems) [mm] | Dimension A1 (profiled rail systems) [mm] | Dimension E1 [mm] |
|---|---|---|---|---|---|
| R166289370 | 44.0 | 0.25 | 44 | 22 | 32 |
| R166189371 | 63.0 | 0.3 | 63 | 31.5 | 53 |
| R166189370 | 63.0 | 0.3 | 63 | 31.5 | 53 |
| R166219371 | 34.0 | 0.1 | 34 | 17 | 26 |
| R166219370 | 34.0 | 0.12 | 34 | 17 | 26 |
| R166119371 | 47.0 | 0.15 | 47 | 23.5 | 38 |
| R166119370 | 47.0 | 0.16 | 47 | 23.5 | 38 |
| R166231421 | 70.0 | 0.9 | 70 | 35 | 50 |
| R166231420 | 70.0 | 0.9 | 70 | 35 | 50 |
| R166231321 | 70.0 | 0.9 | 70 | 35 | 50 |
| R166231320 | 70.0 | 0.9 | 70 | 35 | 50 |
| R166239421 | 70.0 | 0.9 | 70 | 35 | 50 |
| R166239420 | 70.0 | 0.9 | 70 | 35 | 50 |
| R166239321 | 70.0 | 0.9 | 70 | 35 | 50 |
| R166239320 | 70.0 | 0.9 | 70 | 35 | 50 |
| R166131421 | 100.0 | 1.2 | 100 | 50 | 82 |
| R166131420 | 100.0 | 1.29 | 100 | 50 | 82 |
| R166131321 | 100.0 | 1.2 | 100 | 50 | 82 |
| R166131320 | 100.0 | 1.29 | 100 | 50 | 82 |
| R166139421 | 100.0 | 1.2 | 100 | 50 | 82 |
| R166139420 | 100.0 | 1.29 | 100 | 50 | 82 |
| R166139321 | 100.0 | 1.2 | 100 | 50 | 82 |
| R166139320 | 100.0 | 1.35 | 100 | 50 | 82 |
| R166271421 | 60.0 | 0.6 | 60 | 30 | 40 |
Common to all listed parts
| Version | Ball rail system |
| Model | Super ball runner block |
| Ball chain | Without ball chain (standard) |
| Self-aligning for compensation of misalignments | With self-alignment |
| Lubrication | Pre-lubricated, preserved |
| Maximum acceleration rate amax [m/s²] | 500.0 |
| Maximum permissible linear speed vmax [m/s] | 5.0 |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
