RL2 Motor Power Cables Parts
Compare RL2 Motor Power Cables
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Compatible Motors | Connection type of motor connector | cable length [m] | Cross Section | Weight [kg] |
|---|---|---|---|---|---|
| R911402150 | MS2x with terminal box E | E (M50) terminal box | 15.0 | 35 | 0 |
| R911402149 | MS2x with terminal box E | E (M50) terminal box | 10.0 | 35 | 0 |
| R911402148 | MS2x with terminal box E | E (M50) terminal box | 5.0 | 35 | 10.52 |
| R911402168 | MS2x with terminal box E | E (M50) terminal box | 15.0 | 25 | 0 |
| R911402167 | MS2x with terminal box E | E (M50) terminal box | 10.0 | 25 | 0 |
| R911402166 | MS2x with terminal box E | E (M50) terminal box | 5.0 | 25 | 0 |
| R911402171 | MS2x with terminal box C | C (M50) terminal box | 15.0 | 35 | 0 |
| R911402170 | MS2x with terminal box C | C (M50) terminal box | 10.0 | 35 | 0 |
| R911402169 | MS2x with terminal box C | C (M50) terminal box | 5.0 | 35 | 0 |
| R914510326 | MS2x with terminal box C | C (M50) terminal box | 2.0 | 35 | 0 |
| R911402161 | MS2x with terminal box C | C (M50) terminal box | 15.0 | 25 | 0 |
| R911402160 | MS2x with terminal box C | C (M50) terminal box | 10.0 | 25 | 0 |
| R914506793 | MS2x with terminal box C | C (M50) terminal box | 6.5 | 25 | 0 |
| R911402159 | MS2x with terminal box C | C (M50) terminal box | 5.0 | 25 | 0 |
| R914510150 | MS2x with terminal box C | C (M50) terminal box | 0.5 | 25 | 0 |
| R911402165 | MS2x with terminal box C | C (M50) terminal box | 15.0 | 16 | 0 |
| R911402164 | MS2x with terminal box C | C (M50) terminal box | 10.0 | 16 | 0 |
| R911402162 | MS2x with terminal box C | C (M50) terminal box | 5.0 | 16 | 0 |
| R911375245 | MS2x with terminal box T | T (M32) terminal box | 5.0 | 6 | 3.33 |
| R911378723 | MS2x with terminal box T | T (M32) terminal box | 20.0 | 6 | 0 |
| R911378722 | MS2x with terminal box T | T (M32) terminal box | 15.0 | 6 | 0 |
| R911378721 | MS2x with terminal box T | T (M32) terminal box | 10.0 | 6 | 0 |
| R911378720 | MS2x with terminal box T | T (M32) terminal box | 7.5 | 6 | 0 |
| R911378719 | MS2x with terminal box T | T (M32) terminal box | 5.0 | 6 | 3.22 |
Common to all listed parts
| Cable Variant | Power Cable |
| Cable Type | ready-made |
| Compatible Drives | IndraDrive |
| Cable Model | Basic |
| Motor-Drive-Connection | extension cable |
| Dynamic bending radius | 7.5xD |
| Static bending radius | 5xD |
| Bending cycles | 5 million |
