XI4 Analog Outputs Parts
Compare XI4 Analog Outputs
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Bit width, output data in the process data image | Weight [kg] | Current requirement Up | Net current module outputs [A] | Output signal |
|---|---|---|---|---|---|
| R911430123 | 12 Bytes | 0.12 | — | — | — |
| R911406114 | 8 bytes (can be set channel-granularly) | 0.13 | max. 80 mA | 0.08 | 4-20 mA |
| R911406112 | 4 bytes (can be set channel-granularly) | 0.11 | max. 55 mA | 0.04 | 4-20 mA |
| R911406115 | 8 bytes (can be set channel-granularly) | 0.12 | max. 80 mA | 0.08 | 0-20 mA |
| R911406111 | 4 bytes (can be set channel-granularly) | 0.11 | max. 55 mA | 0.04 | 0-20 mA |
| R911406117 | 8 bytes (can be set channel-granularly) | 0.12 | max. 55 mA | 0.008 | -10-10 V |
| R911406113 | 4 bytes (can be set channel-granularly) | 0.11 | max. 45 mA | 0.004 | -10-10 V |
| R911406116 | 8 bytes (can be set channel-granularly) | 0.13 | max. 55 mA | 0.008 | 0-10 V |
| R911406110 | 4 bytes (can be set channel-granularly) | 0.11 | max. 45 mA | 0.004 | 0-10 V |
Common to all listed parts
| Connection type | Push-in |
| Connectivity technology | 2-wire technique bipolar, shielded, twisted in pairs |
| Voltage supply | UP via jumper contacts |
| Width [mm] | 12 |
| Height [mm] | 105 |
| Depth [mm] | 99 |
| International protection code | IP20 |
| Protection class | III |
