4 mm² motor cables Parts
Compare 4 mm² motor cables
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Temperature – Static | Dimensions – Length | Weight |
|---|---|---|---|
| 8BCM05X5.1312A-0 | -20°C to +90°C | 5.5 m | 1.5 kg |
| 8BCM0018.1312A-0 | -20°C to +90°C | 18 m | 4.9 kg |
| 8BCM0019.1312A-0 | -20°C to +80°C | 19 m | 5.3 kg |
| 8BCM0009.1312A-0 | -20°C to +90°C | 9 m | 2.5 kg |
| 8BCM0011.1312A-0 | -20°C to +90°C | 11 m | 3.1 kg |
| 8BCM0013.1312A-0 | -20°C to +90°C | 13 m | 3.6 kg |
| 8BCM0014.1312A-0 | -20°C to +90°C | 14 m | 3.9 kg |
| 8BCM0016.1312A-0 | -20°C to +90°C | 16 m | 4.4 kg |
| 8BCM0002.1312A-0 | -20°C to +90°C | 2 m | 0.6 kg |
| 8BCM0003.1312A-0 | -20°C to +90°C | 3 m | 0.8 kg |
| 8BCM0004.1312A-0 | -20°C to +90°C | 4 m | 1.1 kg |
| 8BCM0005.1312A-0 | -20°C to +90°C | 5 m | 1.4 kg |
| 8BCM0006.1312A-0 | -20°C to +90°C | 6 m | 1.7 kg |
| 8BCM0007.1312A-0 | -20°C to +90°C | 7 m | 1.9 kg |
| 8BCM0008.1312A-0 | -20°C to +90°C | 8 m | 2.2 kg |
| 8BCM0010.1312A-0 | -20°C to +90°C | 10 m | 2.8 kg |
| 8BCM0012.1312A-0 | -20°C to +90°C | 12 m | 3.3 kg |
| 8BCM0015.1312A-0 | -20°C to +90°C | 15 m | 4.2 kg |
| 8BCM0017.1312A-0 | -20°C to +90°C | 17 m | 4.7 kg |
| 8BCM0020.1312A-0 | -20°C to +90°C | 20 m | 5.5 kg |
| 8BCM0025.1312A-0 | -20°C to +90°C | 25 m | 6.9 kg |
Common to all listed parts
| Certifications – CE | Yes |
| Certifications – UKCA | Yes |
| Certifications – CRA (Cyber Resilience Act) | Not applicable |
| Certifications – UL | cULus E225616; Power conversion equipment |
| Cable cross section | 4 x 4.0 mm² + 2 x 0.75 mm² + 2 x 1.0 mm² |
| Power lines – Quantity | 4 |
| Power lines – Wire insulation | PP |
| Power lines – Wire colors | Black, brown, blue, yellow/green |
