Siemens 5SE2013-2A

NEOZED fuse-link, D01, 13 A, gG, Un AC: 400 V, Un DC: 250 V, with tin-coated contact-caps

MPN
5SE2013-2A
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Siemens parts? We buy surplus →

What is the Siemens 5SE2013-2A?

NEOZED fuse-link, D01, 13 A, gG, Un AC: 400 V, Un DC: 250 V, with tin-coated contact-caps

Specifications

Model

product brand nameSENTRON
product designationNEOZED fuse link
design of the productWith tin-coated contact caps
product versionPack of 10
design of the fuse linkNEOZED fuse link

General technical data

size of fuse system according to EN 60269-1D01
operating class of the fuse linkgG

Supply voltage

supply voltage — at AC400 V
supply voltage — at DC250 V
operating voltage rated value400 V
protection class IPIP20, with connected conductors
switching capacity current according to IEC 60947-2 rated value50 kA

Dissipation

power loss [W] for rated value of the current at AC in hot operating state per pole1.5 W

Main circuit

operational current rated value13 A

Appearance

color coding of the fuse linkBlack
maximum short-circuit current breaking capacity (Icu) at AC rated value50 kA

Mechanical Design

mounting positionAny, preferably vertical
Net Weight7 g
ambient temperature during operation — minimum-25 °C
ambient temperature during operation — maximum40 °C
environmental categoryUp to 45°C at 95 % rel. humidity

Downloads & documentation

Official documents from Siemens, downloaded directly from the manufacturer.

Data sheets & manuals

5SE2013-2A: frequently asked questions

When can 5SE2013-2A be shipped?

5SE2013-2A is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 5SE2013-2A in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 5SE2013-2A and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 5SE2013-2A, subject to availability and destination.
