Siemens 3NJ6920-3BB11
Accessory for Switch disconnector with fuses In-line design, pluggable current transformer 50/1 A, Cl. 1, 1 VA
- MPN
- 3NJ6920-3BB11
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the Siemens 3NJ6920-3BB11?
accessory for Switch disconnector with fuses In-line design, pluggable current transformer 50/1 A, Cl. 1, 1 VA
Specifications
Model
| product brand name | SENTRON |
| product designation | Current transformer |
| design of the product | accessory for switch disconnector with fuses 3NJ6 |
| product quality calibrated | No |
| operating voltage | 0.72 kV |
| insulation voltage rated value | 3 kV |
| designation of overcurrent limiting factor | FS 5 |
| current — at input rated value | 50 A |
| current — at output rated value | 1 A |
| accuracy class of the current transformer | class 1 |
| value range of the operating frequency | 50/60 Hz |
Protection class
| protection class IP | IP20 |
| suitability for use for outside use | No |
| suitability for use for interior use | Yes |
Connections
| type of electrical connection at output | screw-type terminals |
Mechanical Design
| height | 65 mm |
| width | 44 mm |
| depth | 30 mm |
| fastening method | mounting |
| diameter of inlet opening | 21 mm |
| outer diameter of the push-through conductor maximum | 21 mm |
| Net Weight | 173 g |
Environmental conditions
| ambient temperature during operation — minimum | -10 °C |
| ambient temperature during operation — maximum | 55 °C |
