Schneider Electric TWDXCAISO
Tap isolation box, Modicon M258, for PLC Twido, serial link, screw terminal block, 2 RJ45
- MPN
- TWDXCAISO
- EAN
- 3595863895360
- Category
- Zelio Logic SR2/SR3
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the Schneider Electric TWDXCAISO?
This product is part of Twido range, an offer of connection accessories for RS485 serial link. This serial link tap isolation box is suitable for lines pre-polarized (2 R 620Ohm), RS485 line isolation and line end adaptor (RC 120Ohm, 1nF) applications. It is a tap isolation box with external supply of 24V DC. It is furnished with screw terminal block and 2 connectors RJ45 for electrical connection. It weighs 0.1kg. It supports 35mm symmetrical DIN rail mount. Modicon M258 logic controllers are designated to the machine builders (OEMs). Part of Modicon 30% saving time in assembly, wiring and commissioning.
Specifications
Specifications
| Range of product | Twido |
| Accessory / separate part category | Connection accessories |
| Accessory / separate part type | Tap isolation box |
| Accessory / separate part designation | Tap isolation box |
| Accessory / separate part destination | RS485 serial link |
| Product specific application | Lines prepolarised (2 R 620 Ohm), RS485 line isolation, Line end adaptor (RC 120 Ohm, 1 nF) |
| Range compatibility | Twido programmable controller, Modicon M238 logic controller |
| [Us] rated supply voltage | 24 V |
| Supply circuit type | DC |
| Supply | External |
| Electrical connection | 1 screw terminal block, 2 connectors RJ45 (for tap-off) |
| Mounting support | 35 mm symmetrical DIN rail |
| Net weight | 0.1 kg |
Packaging
| Package 1 | 1 PCE, 12.0 cm × 6.5 cm × 6.6 cm (L × W × H), 156.0 g |
| Package 2 | 24 S02, 40 cm × 30 cm × 15 cm (L × W × H), 4.191 kg |
| Package 3 | 768 P12, 80 cm × 120 cm × 75 cm (L × W × H), 150 kg |
