PanelSeT PHD outdoor heavy duty - enclosure H788 W500 D320 IP65 plain door

Name: PanelSeT PHD outdoor heavy duty - enclosure H788 W500 D320 IP65 plain door
Brand: Schneider Electric
SKU: NSYPHDT753P

MPN: NSYPHDT753P · Brand: Schneider Electric

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	PanelSeT for outdoors operation
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	19.65 kg

Shipping & availability

When can NSYPHDT753P be shipped?

NSYPHDT753P is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up NSYPHDT753P in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for NSYPHDT753P and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for NSYPHDT753P, subject to availability and destination.

Specifications

Range	PanelSeT
Product	PHD
Application	Outdoor heavy duty
Certification	UL conforming to UL 508 A 2007, Bureau Veritas conforming to IEC 61969-3 2011, Bureau Veritas conforming to IEC 61439-5 2010, DEKRA conforming to IEC 62208 2011
Enclosure type	Multi-purpose
Category	Suitable enclosure
Version	PHDZT
Enclosure height with canopy	788 mm
Canopy height	38 mm
Enclosure width	500 mm
Enclosure depth	320 mm
Enclosure mounting	Wall mounted
Device composition	1 body in polyester double reinforced with fibreglass, 1 door in polyester double reinforced with fibreglass, 1 canopy in polyester double reinforced with fibreglass, 1 door retainer in steel with anti-corrosive coating, 1 document pocket in plastic A4 format
Body type	Sealed assembled body
Door type	Plain
Number of doors	1 door(s)
Door opening side	Right or left (120 °)
Lock type	2 points lock, handle with 1242E key lock and padlock
Accessibility for operation	Front
Maximum static load	180 kg
Removable parts	Door by hinges
Material	Polyester double reinforced with fibreglass
Colour	Grey (RAL 7035)
Standards	UL 508 A, IEC 62208, IEC 61969-3, IEC 61439-5
Electrical insulation class	Class II conforming to IEC 61439-1 2011
IP degree of protection	IP65 conforming to IEC 60529
IK degree of protection	IK10 conforming to IEC 62262 (plain door)
Mechanical robustness	Vandal-proof conforming to EN/IEC 61439-5 version 2010
Fire resistance	960 °C conforming to IEC 62208
Ambient air temperature for operation	-45…80 °C conforming to IEC 61969-3 class 1
Ambient air temperature for storage	-25…40 °C
Corrosion withstand	90…100 % conforming to ISO 12944 C4H
Environmental withstand	Solar radiation: class 1 up to 1120 W/m² conforming to IEC 61969-3:2011, Surrounding air withstand: class 1 up to 180 km/h conforming to IEC 61969-3:2011, Ultraviolet degradation test: class 1 conforming to ISO 4892-2:2013, Formation of ice and frost: class 1 conforming to IEC 61969-3:2011, Fauna and flora withstand: class 1 conforming to IEC 61969-3:2011, : class 1 conforming to IEC 61969-3:2011
Thermal management options	Fan: 1500 W for a maximum noise level of 60 dB, Natural: 372 W at -25 °C, Natural: 163 W at 20 °C, Natural: 69 W at 40 °C
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	78.000 cm
Package 1 Width	53.000 cm
Package 1 Length	35.000 cm
Package 1 Weight	19.650 kg
Unit Type of Package 2	PAM
Number of Units in Package 2	10
Package 2 Height	173.000 cm
Package 2 Width	100.000 cm
Package 2 Length	120.000 cm
Package 2 Weight	211.000 kg
Warranty (in months)	18
