Schneider Electric NSYBPN206
Rear panel, PanelSeT SFN, for electrical enclosure H2000 W600mm, external fixing
- MPN
- NSYBPN206
- EAN
- 3606486104644
- Category
- PanelSeT SFN
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the Schneider Electric NSYBPN206?
This steel back panel is purpose-built to assemble a PanelSeT SFN floor standing modular decarbonized steel electrical enclosure for various applications. It has a nominal height and width of 2000 mm and 600 mm, respectively. The panel is made of steel sheet. An epoxy-polyester powder finish provides a smooth appearance. It has a grey (RAL 7035) color. "This product is qualified as a green premium, with minimal use of hazardous substances." "This product is qualified as a green premium, with minimal use of hazardous substances"
Specifications
Specifications
| Range | PanelSeT |
| Accessory / separate part category | Enclosure accessory |
| Product or component type | Rear panel |
| Application | Multi-purpose |
| For enclosure nominal dimensions | - H: 2000 mm W: 600 mm |
| Mounting location | Rear of enclosure |
| Range compatibility | PanelSeT SFN |
| Device composition | Fixing elements, 1 rear panel |
| Material | Steel |
| Net weight | 17 kg |
| Colour | Grey (RAL 7035) |
| Surface finish | Epoxy-polyester powder |
| Fixing mode | By screws - screw type captive - from the outside of enclosure location |
| Height | Nominal: 2000 mm |
| Width | Nominal: 600 mm |
Packaging
| Package 1 | 1 PCE, 202.000 cm × 59.000 cm × 4.000 cm (L × W × H), 17.000 kg |
| Package 2 | 20 PAL, 202.000 cm × 120.000 cm × 55.000 cm (L × W × H), 364.000 kg |
