Schneider Electric LA9RM201
Level control probe, Harmony Control Relays, relay accessories, maximum operating temperature 100°C
- MPN
- LA9RM201
- EAN
- 3389110190755
- Category
- Harmony Control Relays
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the Schneider Electric LA9RM201?
This Harmony Control, LA9 measurement probe is an accessory for control relay. It allows monitoring of liquid level. It is compatible with control relay RM84, RM4L, and RM35LM. This measurement probe is an accessory for control relay, ideal for monitoring of liquid level. It applies to a wide type of industrial automation applications. It also offers integral LED for indicating control status and it is designed to be temperature up to 100 °C. It is compatible with control relay RM84, RM4L, and RM35LM. It provides automatic detection of abnormal electrical values before they incur serious damage to machinery, this helps to reduce your maintenance and downtime costs.
Specifications
Specifications
| Range of product | Harmony Control Relays |
| Product or component type | Level control probe |
| Accessory / separate part designation | Probe for liquid level control |
| Accessory / separate part destination | Liquid level control relay |
| Accessory / separate part category | Relay accessories |
| Product compatibility | RM84, RM4L, RM35LM |
| Diameter | 16 mm |
| Length | 150 mm |
| Type of installation | Cable suspension |
| Net weight | 0.1 kg |
| Maximum ambient air temperature for operation | 100 °C |
Packaging
| Package 1 | 1 PCE, 2.600 cm × 15.700 cm × 2.600 cm (L × W × H), 95.000 g |
| Package 2 | 40 S01, 40.000 cm × 15.000 cm × 15.000 cm (L × W × H), 3.909 kg |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
LA9RM201: frequently asked questions
When can LA9RM201 be shipped?
LA9RM201 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up LA9RM201 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for LA9RM201 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for LA9RM201, subject to availability and destination.
