Schneider Electric BMXDAO1615H

Discrete output X80 - 16 channel isolated triac - 24..240 V AC - severe

MPN
BMXDAO1615H
EAN
3606489485054
Price and lead time confirmed within 1 business day
Request a Quote

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • Ships via

What is the Schneider Electric BMXDAO1615H?

"This discrete triac output module is part of the Modicon X80 range, an offer of common input/output and communication modules, power supplies and racks for Modicon M340 and Modicon M580." "This product is composed of 16 output channels and it is supplied with 24 to 240V AC." "This ruggedized product can be used in more severe environments, and operate in an extended temperature range, from -25°C to +70°C/-13°F to 158°F." "Modicon X80 modules provide a single environment for the deployment of I/O modules in automation architectures by reducing spare parts inventory, maintenance and training costs." "This product is IP20 rated and offers 500837 hours of MTBF." "This discrete module has a weight of 0.250kg and dimensions of 32x131x86mm." "This product meets the needs of our customers from Smart Infrastructure, Water and Waste Water, Consumer Packaged Goods, Mining Minerals Metals, Data centers and Power generation." "This product is certified by CE, UL, CSA, RCM, EAC, UKCA, Merchant Navy and meets EN 61000-6-5, EN 61850-3, EN 61131-2 standards." "This module is compatible with Modicon M340, M580 (Local or Remote I/O) PLCs with a 40-way caged or spring-type removable terminal block." "The product must be installed on the rack and fixed with 2 screws." PartnerPLC sources new and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of productModicon X80
Product or component typeDiscrete output module

Complementary

Response time on output<= 10 ms resistive activation; <= 10 ms resistive deactivation
Maximum voltage drop<1.55 V at state 1
Insulation resistance> 10 MOhm 500 V DC
Current per channel1.2 A at 60 °C; 0.6 A at 70 °C
Maximum current per module4 A 60 °C; 2 A 70 °C
Inrush current30 A
Output current limits0.005…10 A
MTBF reliability500000 H
Protection type1 external fuse4 A fast blow
Net weight0.264 kg

Environment

IP degree of protectionIP20
Protective treatmentConformal coating
Dielectric strength3000 V AC at 50/60 Hz 1 min
Relative humidity5…95 % at -25…70 °C without condensation
Environmental characteristicGas resistant class Gx; Gas resistant class 3C4; Dust resistant class 3S4; Sand resistant class 3S4; Salt resistant level 2; Mold growth resistant class 3B2

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

BMXDAO1615H: frequently asked questions

When can BMXDAO1615H be shipped?

BMXDAO1615H is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up BMXDAO1615H in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for BMXDAO1615H and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BMXDAO1615H, subject to availability and destination.
