Pepperl Fuchs TCU1100-* (Intel® Atom Elkhart Lake Processor, Windows 11)
Thin Client Unit (TCU)
- MPN
- TCU1100-* (Intel® Atom Elkhart Lake Processor, Windows 11)
- Category
- Industrial Monitors
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the Pepperl Fuchs TCU1100-* (Intel® Atom Elkhart Lake Processor, Windows 11)?
Modular, lightweight design
Low-power design with minimal heat dissipation
VisuNet RM Shell installed
High connectivity flexibility due to multiple interface options
Certified for ATEX and IECEx Zone 1/21
IP66
Thin Client Unit, Modular, lightweight design, Low-power design with minimal heat dissipation, VisuNet RM Shell installed, High connectivity flexibility due to multiple interface options, Certified for ATEX and IECEx Zone 1/21, IP66
Specifications
Hardware
| Order code (Pepperl+Fuchs part number) | T233191 |
| Processor | Intel® Atom Elkhart Lake x6211E |
| RAM | 4 GB |
| Mass storage | 64 GByte industrial grade MLC SSD |
| Lifecycle | Active (current Pepperl+Fuchs product) |
Supply
| Input voltage | 24 V DC ± 10 % (SELV/PELV) |
| Power consumption | 14 W average, 30 W max. |
Interface
| Interface type | Standard:1 x Ethernet 100/1000BASE-TX (Ex e) or 1 x fiber optic 1000BASE-SX (Multimode) or 1 x fiber optic 1000BASE-LX (Singlemode), 1 x USB 2.0 (Ex e; service port), 2 x USB 1.1 (Ex i; intended for Pepperl+Fuchs keyboard and mouse) Optional:1 x barcode reader interface Pepperl+Fuchs Pscan-D/B (Ex i) "S3": 1 x barcode reader interface for wired 1-D scanners IDM-160-D*, IDM-Z1-160-D-* and base station IDMx61-B-* and IDM-Z1-x61-B-* (Ex i) "S4": 1 x barcode reader interface for wired 2-D Scanner IDM-Z1-260-D-* (Ex i) "S5": 1 x RS-232 interface with Power Supply for miscellaneous devices and peripherals (Ex i) 1 x RS-232 (Ex e) 1 x RS-485 (Ex e) 1 x Ethernet 100/1000Base-TX (Ex e) Bluetooth v4.0, communication distance up to 30 m in open terrain, transmission power +8 dBm, transmission frequency 2.402 ... 2.48 GHz |
Directive conformity
| Electromagnetic compatibility: Directive 2014/30/EU | EN 61326-1:2013 (industrial locations) ; EN 61000-6-4:2007+A1:2011 |
| RoHS: Directive 2011/65/EU (RoHS) | EN 50581:2012-09 |
Software
| Operating system | VisuNet RM Shell 6 (based on Windows® 11 IoT Enterprise LTSC 2024) Optional: TSJ-: IGEL OS 12 (based on Linux, pre-installed without licence) TSI-: IGEL OS 11 (based on Linux, pre-installed without licence) (pending) |
Ambient conditions
| Operating temperature | -20 ... 65 °C (-4 ... 149 °F) |
| Storage temperature | -20 ... 65 °C (-4 ... 149 °F) |
| Relative humidity | 93% at 40°C, non-condensating, according to EN 60068-2-78 |
| Shock resistance | 18 shocks 15 g , 11 ms all axis, IEC 60068-2-27 |
| Vibration resistance | 10 ... 150 Hz, +/- 0.075 mm , 1g, 10 cycles per axis according to EN60068-2-6 |
Mechanical specifications
| Degree of protection | IP66 ( when mounted on the display unit from Pepperl+Fuchs ) |
| Material: Housing | anodized aluminum |
| Mass | approx. 5 kg |
| Dimensions | 280 mm x 240 mm x 43 mm |
Data for application in connection with hazardous areas
| EU-type examination certificate | BVS 16 ATEX E 083 X |
| Marking | II 2G Ex eb q [ib] IIC T4 IP66 Gb [exsign] II 2D Ex tb [ib] IIIC T85°C IP66 Db |
| Directive conformity: Directive 2014/34/EU | EN 60079-0:2012+A11:2013, EN 60079-5:2015, EN 60079-7:2015, EN 60079-11:2012, EN 60079-31:2014 |
International approvals
| IECEx approval | IECEx BVS 16.0060X |
| Approved for | Ex eb q [ib] IIC T4 IP66 GbEx tb [ib] IIIC T85°C IP66 Db |
| Standards | IEC 60079-0:2011, IEC 60079-5:2015, IEC 60079-7:2015, IEC 60079-11:2011, IEC 60079-31:2013 |
