Mitsubishi Electric ME96SSR-MB

Mitsubishi Power monitoring MODBUS RTU

MPN: ME96SSR-MB
Category: Mitsubishi Power monitoring – Meters

Price and lead time confirmed within 1 business day

Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original ME96SSR-MB (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Mitsubishi Electric ME96SSR-MB?

The Mitsubishi Electric ME96SSR-MB is a MODBUS RTU in the Power monitoring. Mitsubishi Electric has discontinued it (2013/12 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Power monitoring
Category	MODBUS RTU
Sales status	2013/12 Discontinued (Mitsubishi Electric)

Specifications

Category	Electrical Indicators
Group	Electronic Multi-Measuring Instrument
Model	ME96 series standard model
Model name	ME96SSR-MB
Phase wire system	3-phase 4-wire, 3-phase 3-wire (3CT, 2CT), 1-phase 3-wire, 1-phase 2-wire (common use)
Rating: Current	5A AC, 1A AC (common use)
Rating: Voltage	3-phase 4-wire : max 277/480V AC 3-phase 3-wire : (DELTA) max 220V AC, (STAR) max 440V AC 1-phase 3-wire : max 220/440V AC 1-phase 2-wire : (DELTA) max 220V AC, (STAR) max 440V AC
Rating: Frequency	50/60Hz (common use)
Measuring element: Current (A): Measuring Item	A1, A2, A3, AN, A AVG
Measuring element: Current (A): Class	±0.2%
Measuring element: Current demand (DA): Measuring Item	DA1, DA2, DA3, DAN, DA AVG
Measuring element: Current demand (DA): Class	±0.2%
Measuring element: Voltage (V): Measuring Item	V12, V23, V31, V AVG (L-L), V1N, V2N, V3N, V AVG (L-N)
Measuring element: Voltage (V): Class	±0.2%
Measuring element: Active power (W): Measuring Item	W1, W2, W3, ΣW
Measuring element: Active power (W): Class	±0.5%
Measuring element: Reactive power (var): Measuring Item	var1, var2, var3, Σvar
Measuring element: Reactive power (var): Class	±0.5%
Measuring element: Apparent power (VA): Measuring Item	VA1, VA2, VA3, ΣVA
Measuring element: Apparent power (VA): Class	±0.5%
Measuring element: Power factor (PF): Measuring Item	PF1, PF2, PF3, ΣPF
Measuring element: Power factor (PF): Class	±2.0%
Measuring element: Frequency (Hz): Measuring Item	Hz
Measuring element: Frequency (Hz): Class	±0.5%
Measuring element: Active energy (Wh): Measuring Item	Imported, Exported
Measuring element: Active energy (Wh): Class	class 1.0 (IEC62053-21)
Measuring element: Reactive energy (varh): Measuring Item	Imported lag, Imported lead, Exported lag, Exported lead
Measuring element: Reactive energy (varh): Class	class 2.0 (IEC62053-23)
Measuring element: Harmonic current (HI): Measuring Item	Total, 1 st to 13 st (Odd degree only)
Measuring element: Harmonic current (HI): Class	±2.0%
Measuring element: Harmonic voltage (HV): Measuring Item	Total, 1 st to 13 st (Odd degree only)
Measuring element: Harmonic voltage (HV): Class	±2.0%
Measuring element: Periodic active energy (Wh): Measuring Item	Periodic active energy 1, Periodic active energy 2
Measuring element: Periodic active energy (Wh): Class	class 0.5 (IEC62053-22)
Measuring element: Operating time (h): Measuring Item	Operating time 1, Operating time 2
Measuring element: Operating time (h): Class	(Reference)
Measuring method: Instantaneous value	A/V: RMS calculation, W/ var/ VA/ Wh/ varh: Digital multiplication, PF: Power ratio calculation, Hz: Zero-cross, HI/HV: FFT
Measuring method: Demand value	DA: Thermal type calculation
Display: Display type	LCD with LED backlight
Display: Number of display digits or segments: Digital section	6 digits each at upper, middle, and lower line A, DA, V, W, var, VA, PF: 4 digits Hz: 3 digits Wh, varh: 9 digits (6 or 12 possible) Harmonic distortion ratio, content ratio: 3 digits Harmonic RMS: 4 digits Operating time: 6 digits Contact input/output: I/O
Display: Number of display digits or segments: Bar graph	21 segment bar graph, 22 segment indicator
Display: Display update time interval	0.5s or 1s (selectable)
Transmission function: Transmission type	MODBUS RTU
Transmission function: Transmission speed	2400, 4800, 9600, 19200, 38400bps
Transmission function: Connection method	Multi-drop
Transmission function: Transmission distance	1,200m (max)
Transmission function: Number of connectable units	31 units
Connectable Optional Plug-in Module	ME-4210-SS96, ME-0040C-SS96, ME-0052-SS96
Power interruption backup	Non-volatile memory used (items: setting value, max/min value, active/reactive energy, periodic active energy, operating time)
VA Consumption: Voltage circuit	Each phase 0.1VA (110V AC), 0.2VA (220V AC)
VA Consumption: Current circuit	Each phase 0.1VA (5A AC)
VA Consumption: Auxiliary power circuit	7VA (at 110V AC), 8VA (at 220V AC), 5W (at 100V DC)
Auxiliary power	100-240V AC (±15%), 100-240V DC (-30% +15%)
Weight	0.5kg
Dimensions	96 (H) x 96 (W) x 86 (D)
Mounting method	Embedded
Operating temperature	-5 to +55°C (Average: 35°C or less)
Operating humidity	0 to 85%RH (non condensing)
Storage temperature	-25 to +75°C (Average: 35°C or less)
Storage humidity	0 to 85%RH (non condensing)
