Mitsubishi Electric ME110SSR
Mitsubishi Power monitoring Meter
- MPN
- ME110SSR
Price and lead time confirmed within 1 business day
Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original ME110SSR (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the Mitsubishi Electric ME110SSR?
The Mitsubishi Electric ME110SSR is a meter in the Power monitoring. Mitsubishi Electric has discontinued it (2024/03 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | Power monitoring |
| Sales status | 2024/03 Discontinued (Mitsubishi Electric) |
Specifications
| Category | Electrical Indicators |
| Group | Electronic Multi-Measuring Instrument |
| Model | ME110 Super-S Series |
| Model name | ME110SSR |
| Phase wire system | 3-phase 4-wire, 3-phase 3-wire (3CT, 2CT), 1-phase 3-wire, 1-phase 2-wire (common use) |
| Rating: Current | 5A AC, 1A AC (1A AC is special-purpose item) |
| Rating: Voltage | 3-phase 4-wire : max 277/480V AC 3-phase 3-wire : 110V AC, 220V AC 1-phase 3-wire : 220V AC (110/220V AC) 1-phase 2-wire : 110V AC, 220V AC |
| Rating: Frequency | 50-60Hz |
| Measuring element: Current (A): Measuring Item | 3P4W : A1, A2, A3, AN, A AVG 3P3W, 1P3W : A1, A2, A3 1P2W : A1 |
| Measuring element: Current (A): Class | 0.5% |
| Measuring element: Current demand (DA): Measuring Item | 3P4W : DA1, DA2, DA3, DAN, DA AVG 3P3W, 1P3W : DA1, DA2, DA3 1P2W : DA1 |
| Measuring element: Current demand (DA): Class | 0.5% |
| Measuring element: Voltage (V): Measuring Item | 3P4W : V12, V23, V31, V AVG (L-L), V1N, V2N, V3N, V AVG (L-N) 3P3W, 1P3W : V12, V23, V31 1P2W : V12 |
| Measuring element: Voltage (V): Class | 0.5% |
| Measuring element: Active power (W): Measuring Item | 3P4W : ΣW, W1, W2, W3 3P3W, 1P3W, 1P2W : ΣW |
| Measuring element: Active power (W): Class | 0.5% |
| Measuring element: Active demand power (DW): Measuring Item | 3P4W : ΣDW, DW1, DW2, DW3 3P3W, 1P3W, 1P2W : ΣDW |
| Measuring element: Active demand power (DW): Class | 0.5% |
| Measuring element: Reactive power (var): Measuring Item | 3P4W : Σvar, var1, var2, var3 3P3W, 1P3W, 1P2W : Σvar |
| Measuring element: Reactive power (var): Class | 0.5% |
| Measuring element: Apparent power (VA): Measuring Item | 3P4W : ΣVA, VA1, VA2, VA3 |
| Measuring element: Apparent power (VA): Class | 0.5% |
| Measuring element: Power factor: Measuring Item | 3P4W : Σcosφ, cosφ1, cosφ2, cosφ3 3P3W, 1P3W, 1P2W : Σcosφ |
| Measuring element: Power factor: Class | 2.0% |
| Measuring element: Frequency (Hz): Measuring Item | Hz |
| Measuring element: Frequency (Hz): Class | 0.5% |
| Measuring element: Active energy (Wh): Measuring Item | Imported, Exported |
| Measuring element: Active energy (Wh): Class | 2.0% |
| Measuring element: Reactive energy (varh): Measuring Item | Import Capacitive, Import Inductive, Export Capacitive, Export Inductive |
| Measuring element: Reactive energy (varh): Class | 2.0% |
| Measuring element: Harmonic current (HI): Measuring Item | 3P4W : HI1, HI2, HI3, HIN 3P3W, 1P3W : HI1, HI3 1P2W : HI1 THD, h1...h13 (without even number) RMS value and Distortion ratio (max.100%) |
| Measuring element: Harmonic current (HI): Class | 2.5% (Total RMS, 0 to Rated x 60%) |
| Measuring element: Harmonic voltage (HV): Measuring Item | 3P4W : HV1N, HV2N, HV3N 3P3W, 1P3W : HV12, HV23 1P2W : HV12 THD, h1...h13 (without even number) RMS value and Distortion ratio (max.20%) |
| Measuring element: Harmonic voltage (HV): Class | 2.5% (THD, 0 to 20%) |
| Measuring Method: Instantaneous Value | A, V : RMS calculation, W, var, VA, Wh, varh : Digital multiplication, cosφ: Power ratio calculation, Hz : Zero-cross, HV, HI : FTT |
| Measuring Method: Demand Value | Thermal type calculation |
| Display: Display type | LCD with backlight |
| Display: Number of display digits or segments: Digital section | A, DA, V, W, DW, var, VA, cosφ: 4 digits Hz, HI, HV : 3 digits Wh, varh : 6 digits |
| Display: Number of display digits or segments: Bar graph | 21 Segment-Bar graph, 22 Segment-Indicator |
| Display: Display update time interval | 0.5s / 1s |
| Response time | Display : 4s or less, Analog output : 4s or less In HI and HV, 10s or less |
| Power interruption backup | Non volatile memory (Items : setting value, max/min value, active/reactive energy) |
| VA Consumption: Voltage circuit | 0.1VA/phase, 0.2VA/phase (at direct input) |
| VA Consumption: Current circuit | 0.1VA/phase |
| VA Consumption: Auxiliary power circuit | 8VA at 110VAC, 9VA at 220VAC, 6W at 100VDC |
| VA Consumption: Digital input | DC19-30V, under 7mA |
| Auxiliary power | 100 to 240VAC (+10%, -15%) 50/60Hz 100VDC (+10%, -30%) |
| Weight | 0.5kg |
| Dimensions | 110(H) x 110(W) x 98(D) |
| Enclosure | Thermoplastic self-extinguish (UL94V0) |
| Operating temperature | -5°C to +50°C (average operating temperature : 35°C or less per day) |
| Operating humidity | 85%RHmax, non condensing |
| Storage temperature | -20°C to +60°C |
