Mitsubishi Electric A6BR10

Mitsubishi MELSEC network modules Option

MPN: A6BR10
Category: Mitsubishi MELSEC-A Series (large type, discontinued)

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric A6BR10?

The Mitsubishi Electric A6BR10 is a option in the MELSEC network modules. Repeater for MELSECNET/H and MELSECNET/10 coaxial bus system, input voltage: 100...240 V AC. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	MELSEC network modules
Category	Option
Type	Coaxial bus
Subtype	Repeater for coaxial bus
Outline	Repeater for MELSECNET/H and MELSECNET/10 coaxial bus system, input voltage: 100...240 V AC

Specifications

Communication speed	10 Mbps
Maximum number of units to be installed per network	4
Extension distance per unit	300 m (3C-2V), 500 m (5C-2V, 5C-FB)
Overall cable distance	300 m × 5 = 1.5 km (3C-2V) 1.5 km × 5 = 2.5 km (5C-2V, 5C-FB)
Maximum number of connected stations	32 stations
Alarm output for abnormal continuous transmission	ERR1: On when the A6BR10 is abnomal (a power-off error). ERR2: On when the A6BR10 is nomal.
Alarm output for abnormal continuous transmission: Isolation method	Non-isolated
Alarm output for abnormal continuous transmission: Rated switching voltage/current	24 V DC, 2 A (resistive load), 240 V AC, 2 A (cosø=1)
Alarm output for abnormal continuous transmission: Minimum switching load	5 V DC, 1 mA
Alarm output for abnormal continuous transmission: Maximum switching voltage	264 V AC, 125 V DC
Alarm output for abnormal continuous transmission: Response time: OFF to ON	10 ms or less
Alarm output for abnormal continuous transmission: Response time: ON to OFF	12 ms or less
Alarm output for abnormal continuous transmission: Life: Mechanical	10 million times or more
Alarm output for abnormal continuous transmission: Life: Electrical	Rated switching voltage/current load: More than 100 thousand times 200VAC 1.5A, 240VAC 1A (COSø=0.7): 100 thousand times 200VAC 1A, 240VAC 0.5A (COSø=0.35): 100 thousand times 24VDC 1A, 100VDC 0.1A (L/R=7ms): 100 thousand times
Alarm output for abnormal continuous transmission: Surge suppressor	None
Module power supply: Voltage	100...240 V AC, -15/+10 % (85...264 V AC)
Module power supply: Frequency	50/60 Hz ±5 %
Module power supply: Maximum apparent power	21 VA
Module power supply: Current	0.2 A
Module power supply: Inrush current	40 A, within 8 ms
Module power supply: Efficiency	65 % or more
Module power supply: Allowable momentary power failure time	20 ms
External dimensions: Height	100 mm
External dimensions: Width	170 mm
External dimensions: Depth	80 mm
Weight	1.0 kg

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

Repeater Unit for the MELSECNET/10 Coaxial Bus System type A6BR10/A6BR10-DC User's Manual (IB-66499-C)PDF · 0.70MB
