Keyence LV-H32
Reflective Sensor Head, Spot Type, Variable Spot. . Series: Digital Laser Sensor. Series code: LV series
- MPN
- LV-H32
- Category
- Digital Laser Sensor
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Keyence LV-H32?
Reflective Sensor Head, Spot Type, Variable Spot. LV-H32. Series: Digital Laser Sensor. Series code: LV series
Specifications
Specifications
| Model Name | Reflective Sensor Head, Spot Type, Variable Spot |
| Model Code | LV-H32 |
| Series Title | Digital Laser Sensor |
| Series Code | LV series |
| Data Sheet URL | https://www.keyence.com/download/download/confirmation/?dlSeriesId=WS_SR_lv&dlModelId=PM_153H32&dlSiteId=1&dlLanguageId=en-US&dlLangType=en-US |
| CAD URL | https://www.keyence.com/products/sensor/laser/lv/downloads/?mode=cd&modelId=PM_153H32 |
| Manuals URL | https://www.keyence.com/products/sensor/laser/lv/downloads/?mode=ma&modelId=PM_153H32 |
| Model | LV-H32 |
| Type | Adjustable beam spot |
| FDA (CDRH) Part 1040.10 | Class II |
| Light source | Visible red semiconductor laser |
| Wavelength | 660 nm |
| Detecting distance - FINE | 30 to 250 mm 1.181" to 9.842" |
| Detecting distance - TURBO | 30 to 500 mm 1.181" to 19.685" |
| Detecting distance - SUPER | 30 to 1000 mm 1.18" to 39.37" |
| Environmental resistance - Ambient temperature | -10 to +55 °C 14 to 131 °F (No freezing) |
| Environmental resistance - Relative humidity | 35 to 85 % RH (No condensation) |
| Material - Case | Glass reinforced plastic *1 |
| Material - Lens cover | Acrylic *2 |
| Weight | Approx. 45 g |
LV-H32: frequently asked questions
When can LV-H32 be shipped?
LV-H32 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up LV-H32 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for LV-H32 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for LV-H32, subject to availability and destination.
