Infineon T1500N14TOF-VT
1800 V phase control thyristor disc
- MPN
- T1500N14TOF-VT
- Category
- Thyristor & Diode Modules
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the Infineon T1500N14TOF-VT?
Infineon T1500N14TOF-VT: 1800 V phase control thyristor disc in Disc dia 75mm height 26mm / Ceramic. PartnerPLC supplies new and surplus Infineon power semiconductors for drive, inverter and power-supply repair — request a quote for price, condition and lead time.
Specifications
Specifications
| Clamping force [kn] range | 24 to 56 |
| Configuration | Electrical Triggered Phase Control Thyristor |
| Housing | Disc dia 75mm height 26mm / Ceramic |
| ITAVM/TC [A/°C] (@180° el sin) | 1500/85 |
| ITAVM | 1500 (180 ° el sin) |
| ITSM [A] (@10ms, Tvj max) | 33500 |
| ITSM | 33500 A |
| rT [mΩ] (@Tvj max) max | 0.15 |
| RthJC [K/kW] (@180° el sin) max | 18.4 |
| tq [µs] | 240 |
| Tvj [°C] max | 125 |
| VDRM / VRRM [V] | 1400 |
| VDRM/ VRRM (V) | 1400 V |
| VT/IT [V/kA] (@Tvj max) | 2.10/7.0 |
| VT0 [V] (@Tvj max) max | 0.9 |
| ∫I2dt [A²s · 103] (@10ms, Tvj max) | 5611 |
Ordering codes (OPN)
| T1500N14TOFVTXPSA1 | active and preferred |
T1500N14TOF-VT: frequently asked questions
When can T1500N14TOF-VT be shipped?
T1500N14TOF-VT is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up T1500N14TOF-VT in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for T1500N14TOF-VT and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for T1500N14TOF-VT, subject to availability and destination.
