Honeywell W973A1017/U
W973 Logic Panel
- MPN
- W973A1017/U
Price and lead time confirmed within 1 business day
Discontinued by Honeywell — we can still source the original W973A1017/U (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Honeywell W973A1017/U?
W973 solid state energy management systems control heating, cooling, and economizer operation in commercial air conditioning equipment. The logic panels are compact to fit easily in air conditioning equipment control panel. Panels can be used with staged gas, oil, or electric heat; modulating gas, hot water, or steam heat; and direct expansion or modulating chilled water cooling. The positive modulating low limit starts to close the economizer motor to minimum position if the discharge air temperature drops below factory-set temperature of 62 °F (17 °C). The motor will be at minimum position when discharge temperature is 50 °F (10 °C). W973 logic panels balance system output against space load demand to maintain stable room temperature with minimum temperature swing. The systems recycle to all stages off-on power interruption. When power is restored, the systems sequence stages back on with a time delay between stages. Features & Benefits:
Integrated economizer provided as the first stage of cooling in all models
Load reactive time delays provided ensure stable system performance
1/4 inch male quick-connect terminals provided for wiring connections
Pilot duty SPDT relays control on-off heating and cooling stages
Modulating DC current signal controls economizer and valve motors
Solid state dual set point thermostat located in the controlled space provides heating and cooling input signals
Up to six W973 panels can be controlled from one thermostat
Secondary sensor located in discharge air duct provides anticipation and a positive economizer modulating low limit signalCertifications:
Canadian Standards Association: File No. LR95329-3
Underwriters Laboratories, Inc: Component Recognized, File No. SA481
Honeywell W973A1017/U — W973 solid state energy management systems control heating, cooling, and economizer operation in commercial air conditioning equipment. Discontinued by Honeywell — no longer in the current range. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
Specifications
Product
| Lifecycle | Discontinued by Honeywell |
Ordering codes
| Part numbers on this product page | W973A1017/U, W973B1016/U, W973B1024/U, W973F1004/U, W973J1017/U |
W973A1017/U: frequently asked questions
Can I still buy the W973A1017/U now that it is discontinued?
Yes. Honeywell has discontinued the W973A1017/U, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.
When can W973A1017/U be shipped?
W973A1017/U is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up W973A1017/U in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for W973A1017/U and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for W973A1017/U, subject to availability and destination.
