Honeywell VAVIH-SD
BACtalk® ™ Controller
- MPN
- VAVIH-SD
Price and lead time confirmed within 1 business day
Discontinued by Honeywell — we can still source the original VAVIH-SD (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Honeywell VAVIH-SD?
The Alerton BACtalk® VAViH-SD™ controller with integrated actuator is a versatile BACnet-compliant controller, providing pressure-independent control of any single-duct variable air volume (VAV) box. It features a built-in airflow sensor, five universal inputs (AIs or BIs) and six binary outputs (BOs). As a native BACnet controller, the VAViH-SD integrates seamlessly with your BACnet system, the VAViH-SD-F includes a filter to reduce dust contamination.
The BACtalk VAViH-SD contains an integral airflow sensor to provide pressure independent operation of the VAV box. Each airflow sensor is factory-calibrated at multiple velocity points. Minimum, maximum, and reheat airflows can be entered either at a Microset wall unit or an operator workstation. A technician can adjust airflow parameters in the field during balancing to compensate for slight variations in box installation and type.
The direct-coupled, brushless actuator is a high-reliability, maintenance-free ON-OFF/floating point control model manufactured by Honeywell. Its universal V-bolt clamp assembly mounts directly to the damper operating shaft.
All control algorithms are factory-loaded into non-volatile flash memory and can be completely field-modified. The VAViH-SD can execute control algorithms independently of other equipment. All calibration, programming, and operator entered setup data is stored in flash memory for further assurance of stable, reliable, and independent operation. Features & Benefits:
Economical Comes with 5 inputs, 6 binary outputs
The separate replaceable actuator enables quicker, less expensive repairs
Adaptable Pre-loaded, DIP-switch selectable DDC applications for 5 types of VAV box control
Flexible Left- or right-mountable actuator enables flexible mounting configurations
Innovative Device addressing and application selection can all be done with common tools for easy installation or replacement
Attractive Sleek, updated designCertifications:
FCC Part 15, Class A
EN 55022, Class A
EN 61000-3-2, 61000-3-3, 61000-4-2, 61000-4-3, 61000-4-4, 61000-4-8, 61000-4-6, 61000-4-11
Honeywell Alerton VAVIH-SD — The Alerton BACtalk® VAViH-SD™ controller with integrated actuator is a versatile BACnet-compliant controller, providing pressure-independent control of any single-duct variable air volume (VAV) box. Discontinued by Honeywell — no longer in the current range. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
Specifications
Product
| Lifecycle | Discontinued by Honeywell |
| Brand line | Alerton |
Others
| Brand | Alerton |
Ordering codes
| Part numbers on this product page | VAVIH-SD, VAVIH-SD-F |
VAVIH-SD: frequently asked questions
Can I still buy the VAVIH-SD now that it is discontinued?
Yes. Honeywell has discontinued the VAVIH-SD, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.
When can VAVIH-SD be shipped?
VAVIH-SD is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up VAVIH-SD in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for VAVIH-SD and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for VAVIH-SD, subject to availability and destination.
