Honeywell FC00535B

What is the Honeywell FC00535B?

Fire Fighter’s Handsets provides two-way emergency telephone communication between the fire fighters and other authorized personnel who control a Life Safety System. It is designed for use with a variety of life safety control systems. An added benefit is its easy integration with systems that have addressable and zone telephone circuits in a single, flexible product package.

Typically, the Fire Fighter’s Handset is installed in the following locations in a facility.

Corridors

Stairways

Lobbies

Mechanical control centres

other strategic locations

When you lift the handset from the cradle, it activates a visible indication (LED) signalling that contact is positively initiated. This feature indicates the ETC phone is ready for the operator to communicate with the system that is connected to the building’s Fire Fighter Emergency Telephone Communications System. It is field configurable for different voltage operations used for both supervised and no supervised systems. The unit has a red epoxy finish with enhanced graphics in white indelible ink that is permanently marked for identification. It also includes optional surface or flush mounting with no visible hardware. Features & Benefits:

Constructed of durable, red finish and 16” (41 cm) gauge steel construction

Contains surface or flush back box

No tools required - use slide pins to insert the removable door

Offers clearly marked, raised clamp terminals for field wiring

Has a key lock or break glass access

Includes two cabinet door options: - Key lock latch door - NYC warden station magnetic latch door with pull handle

Overall back box dimensions: 9” W x 13” H x 4” D (23 x 33 x 10 cm) includes a 1” (2.5 cm) extension flange

Provides multiple voltages / supervised polarity equippedCertifications:

Listed under UL® Standard 864 9th Edition

Complies with the ADA standards for surface mount

UL Listed: S1949, 2572 for Mass Notification

MEA Approved, Fire Dept. of New York: COA# 6077

CSFM: 7165-1703:0125

ISO 9001 Certification

Honeywell Gamewell-FCI FC00535B — The Fire Fighter’s Handsets are designed for use with a variety of life safety control systems. They provides two-way emergency telephone communication between fire fighters and other authorized personnel for a life safety system. Discontinued by Honeywell — no longer in the current range. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
